Vmd20 Small Home Use 3 Axis Milling Machine Precision Desktop Drilling
| US$1,200.00-1,500.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
VMD20
Structure
Vertical
Layout
Vertical
Controlling Mode
Motor
Number of Shaft
3
Hole Diameter
<50mm
Automatic Grade
Semiautomatic
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Transport Package
in Wooden Case
Specification
Standard configuration
Trademark
GESEN
Origin
China
HS Code
8459590000
Production Capacity
50000sets/Year
Product Description
Household Micro Drilling Milling Machine VMD20Household Micro Drilling Milling Machine VMD30
Parameters
| Parameters | VMD20 | VMD30 | VMD38 | VMD48 |
| Maximum drilling diameter | 20mm | 26mm | 38mm | 48mm |
| Maximum face milling capacity | 53mm | 63mm | 63mm | 80mm |
| Maximum vertical milling capacity | 18mm | 23mm | 21mm | 32mm |
| Maximum tapping capacity | M30 | M30 | ||
| Workbench size | 500×145mm | 700×180mm | 700×180mm | 800×240mm |
| T-slot size | 10mm | 12mm | 12mm | 16mm |
| X-axis travel | 300mm | 480mm | 500mm | 580mm |
| Y-axis travel | 160mm | 175mm | 175mm | 200mm |
| Z-axis travel | 220mm | 270mm | 320mm | 350mm |
| Spindle taper | MT2 | MT3 | MT3 | MT4 |
| Spindle stroke | 50mm | 50mm | 80mm | 130mm |
| Distance spindle axis to column guide | 170mm | 200mm | 203mm | 260mm |
| Spindle end to table distance | 280mm | 300mm | 445mm | 450mm |
| Headstock swirl angle around | ±45° | ±45° | ±45° | ±45° |
| Spindle speed/Grade | 50-2250rpm | 50-2250rpm | 95-1420rpm/6 | 80-1250rpm/6 |
| Motor | 750w | 1000w | 0.75kw | 1.5kw |
| N.W./G.W. | 78kg/100kg | 125kg/150kg | 200/245kg | 330/380kg |
| Machine size | 670*550*760mm | 860*550*870mm | 730*840*1010mm | 845*910*1020mm |
Industrial Drilling Milling Machine VMD38 VMD48
Optional configuration:
X-axis auto-feeding; 3-axis digital display; ground cabinet. Model VMD38
