Massage Gel and Lubricant Mixing Emulsifying Equipment/Emulsifying Machine

Product Description

Massage Gel and Lubricant Mixing Emulsifying Equipment/Emulsifying Machine
GENERAL CONSIDERATIONS.
L&B BRL-3 High shear mixer is used for the mixing, homogenizing between liquid and liquid, or powder and liquid, Belongs to the L&B High shear mixer series.
BRL-3 High shear mixer is used for the continuous dispersing and emulsifying of material with different phase. Meanwhile the mixer could also delivery low viscosity liquid.
The mixer could mixing the powder and liquid in certain rate, and have been used in cosmetic, food, pharmaceutical, chemical, petroleum, coatings, nano-materials industry
All the sanitary, reliability and rigidity meets the requirements of these industries.


OPERATION THEORY.
The mixer is composed of a few standard spare parts, which makes assembly, disassembly and maintenance easy, meanwhile avoid returning factory to repair.
Specially designed mixing head is composed of rotor and stator.
The rotor works in high speed and high-frequency mechanical effects from the motor.
The material is under the shear, centrifugal squeeze, deep friction, impact and tearing turbulence combined effects, thus achieve the effect of dispersion, emulsification, grinding.
High shear emulsifier combined of two layers or six layers of rotor and stator.
The materials go through the layers after shear dispersion and emulsifying.
APPKUCATION:
L & B Inline high shear mixer is usually installed in the bottom of the reactor or pipeline, the material go through form inlet to outlet , after high-speed shear. This process could be done continuously or in circulation.
Flow quantity: Q=4-140T/h

Viscosity range of delivering material: 0.2cp-3000cp

Max pressure at outlet: 0.05-0.2Mpa

Product temperature range: -30ºC-150ºC

We are specialized in producing different kinds of valves, pipe fitting, tubes, manhole covers, pumps, tanks etc for many years. We can design the products according to your special request. OEM is welcome too.

Model	Power (kw)	Speed (rpm)	Flow (m³/h)
BRL3-60	4	2800	0-4
BRL3-100	7.5	2800	0-8
BRL3-120	11	2800	0-12
BRL3-140	15	2800	0-18
BRL3-165	22	2800	0-22
BRL3-200	37	2800	0-30
BRL3-220	55	2800	0-40
BRL3-240	75	2800	0-55
BRL3-260	90	1480	0-65
BRL3-300	110	1480	0-80
BRL3-360	132	1480	0-100
BRL3-380	160	1480	0-120
BRL3-400	185	1480	0-140
