Cement Making Equipment Rotary Kiln for Clinker Manufacturing Production Plant

Product Description

Cement Making Equipment Rotary Kiln For Clinker Manufacturing Production Plant
Product name: Rotary Kiln/ Rotary Calciner
Application: Cement clinker, Quick Lime, ZnO recovery, LECA, Anthracite, Alumina, Bauxite, Ceramic Sand, etc.
Capacity: 300-3000 t/d
Fuel: Diesel, Gas, Coal, Electricity, etc.
Rotary Kiln for Cement Production Plant:
1. Easy to setup, operate and adjust
2. Reasonable and multiple matching
3. Low price
4. Best after service! ! !
Clinker cement production line mainly has lifting equipment, drying equipment, grinding equipment, transmission equipment, dust removal equipment, and packaging equipment, etc. According to different plant design production planning, a variety of equipment also need to customize.
Our company has a long-term production equipment design, manufacturing and installation experience. We have extensive experience for producing 1600 tons / day cement production line project. We can provide the appropriate technical support to all the clients, including select equipment model.
It has the advantages as followings:
1) Low energy consumptionan and high efficiency
2) Little pollution
3) Long life using
4) Stable performance
5) High output, Low Power Consumption.
Features of rotary kiln:
1. Stable function, low energy consumption, high output, easy to operate. Rotary kiln's structure is simple, production process control conveniently and reliably and it is less wearing parts and high operation rate.
2. One hand, rotary kiln is the combustion equipment, in which coal powder burns to produce heat; Another hand, rotary kiln is the heat transfer equipment, raw materials absorb the gas heat to burn. Fuel combustion, heat transfer and material movement must be reasonable co-ordination to make the heat produced by material burn transfer to raw material timely when raw material go through the rotary kiln. This can reach the high-yield, high-quality and low consumption of purpose.
3. The rotary kiln firing system is equipmented with technological innovation, This system adopts the domestic advanced technology, such as the most advanced hydraulic block wheel device, a high measurement accuracy of measurement piston pump, high-precision control valve and contact-type graphite block sealing device.
4. Easy to operate, reliable use. Stabilize the thermal system, and improve the equipment operation rate, increase 10% operation rate compared with the same specifications equipment, production increased by 5% -10%, reduction 15% heat loss.
Parameter of Cement Rotary Kiln:

Product specifications(m)	Kiln dimensions			Capacity(t/d)	Rotation speed(r/min)	Motor power(kw)	Total weight(t)	Note
	Diameter(m)	Length(m)	Obliquity(%)
Φ2.5×40	2.5	40	3.5	180	0.44-2.44	55	149.61	Kiln with shaft cyclone preheater
Φ2.5×50	2.5	50	3	200	0.62-1.86	55	187.37	----
Φ2.5×54	2.5	54	3.5	204	0.48-1.45	55	196.29	----
Φ2.7×42	2.7	42	3.5	320	0.10-1.52	55	198.5	----
Φ2.8×44	2.8	44	3.5	400	0.437-2.18	55	201.58	Outside disassemble kiln
Φ3.0×45	3	45	3.5	500	0.5-2.47	75	210.94	----
Φ3.0×48	3	48	3.5	700	0.6-3.48	100	237	Outside disassemble kiln
Φ3.0×60	3	60	3.5	300	0.3-2	100	310	Alumyte-alumina forge kiln
Φ3.2×50	3.2	50	4	1000	0.6-3	125	278	Outside disassemble kiln
Φ3.3×52	3.3	52	3.5	1300	0.266-2.66	125	283	Kiln with preheater precalcine
Φ3.5×54	3.5	54	3.5	1500	0.55-3.4	220	363	Kiln with preheater precalcine
Φ3.6×70	3.6	70	3.5	1800	0.25-1.25	125	419	Generating kiln for using ofterheat
Φ4.0×56	4	56	4	2300	0.41-4.07	315	456	Kiln with preheater precalcine
Φ4.0×60	4	60	3.5	2500	0.396-3.96	315	510	Kiln with preheater precalcine
Φ4.2×60	4.2	60	4	2750	0.4-3.98	375	633	Kiln with preheater precalcine
Φ4.3×60	4.3	60	3.5	3200	0.396-3.96	375	583	Kiln with preheater precalcine
