High Quality Second Hand 51m Concrete Pump Truck Sym5360thbfs 510c-10 for Sale
| US$50,000.00-60,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SYM5360THBFS
Shotcrete Type
Wet
Machining Process
Hydraulic
Structure
Rotor Type
Productivity
240m²/h
Feeding Height
1400mm
Vibrating Amplitude
2.6mm
Certification
ISO9001: 2000, CE
Condition
Used
Color
Red
Full Length
12350mm
Overall Width
2550mm
Total Height
4000mm
Total Weight
36000kg
Hydraulic System
Open
Theoretical Pumping Pressure Low Pressur
8.3MPa
Theoretical Pumping Pressure High Pressu
13MPa
Transport Package
Rude Packing
Specification
36000kg
Trademark
Original
Origin
China
HS Code
8705909100
Product Description
High Quality Second Hand 51M Concrete Pump Truck Sym5360thbfs 510c-10 for SaleProduct Description
1. Strong site adaptability, strong escape ability, large displacement, large bridge length ratio, large material distribution range.
2. 6-section RZR boom, the end boom can be reversed 180° for high-rise fabric construction, which cannot be reversed, and the range is more than 50%. The boom is truly flat at 0°, and there is no moisture in the horizontal fabric range.
3. 12MPa high pressure at the outlet, automatically adapt to pumping technology anti-blocking pipe, high and low pressure one-button switching, continuous inching anti-blocking pipe, large-diameter swing cylinder reversing is powerful.
Product Parameters
| Concrete theoretical displacement low pressure | 180m³/h |
| Concrete theoretical displacement high pressure | 120m³/h |
| Theoretical pumping pressure low pressure | 8.3Mpa |
| Theoretical pumping pressure high pressure | 13Mpa |
| Theoretical pumping times low pressure | 29 times/minute |
| Theoretical pumping times high pressure | 20 times/minute |
| Inner diameter of conveying cylinder | 260mm |
| Delivery cylinder stroke | 1900mm |
| Hydraulic system | Open |
| System oil pressure | 32Mpa |
| Fuel tank capacity | 680L |
| Water tank capacity | 620L |
| Delivery pipe diameter | 125mm |
| End hose length | 3m |
| End hose diameter | 125mm |
Detailed Photos
