Uni-T Ut71c Manual Digital Multimetro Intelligent Professional Multimeter
| US$50.00-150.00 | 5 Pieces (MOQ) |
Basic Info.
Model NO.
Ut71c
Installation
Portable
Display Mode
Digital
Accuracy
0.5%~1%
Theory
Electric Apparatus
Power Source
AC and DC
Connection Type
USB
Maximum Scale
1999
Range Conversion Type
AUTO RANGZ
Additional Measuring Item
Frequency
Display
LCD
Power
3V Battery(Cr2032)
LCD Size
43mm X 22mm
Product Color
Red and Grey
Product Net Weight
76g
Product Size
110mm X 58.2mm X 10.8mm
Standard Accessories
Battery,Carrying Case
Standard Individual Packing
Blister, English Manual
Standard Quantity Per Carton
90 PCS
Standard Carton Measurement
528mm X 323mm X 400mm (0.068 Cbm Per Export Carton
Standard Carton Gross Weight
13.5 Kg
Transport Package
Carton with Foam Inside
Specification
CE/ISO/IEC
Trademark
HuaZheng
Origin
Hebei, China
HS Code
9030320000
Production Capacity
200PCS/Month
Product Description
Uni-t Ut71c Manual Digital Multimetro Intelligent MultimeterI. Product Description of Uni-t Ut71c Manual Digital Multimetro Intelligent Multimeter
UT71C 39999 count is 4 3/4 Auto range True RMS digital multimeter with analog bar graph display full-featured, full-range overload protection and unique design, making it more superior performance of high-precision electrical measuring instruments.
II. Parameter of Uni-t Ut71c Manual Digital Multimetro Intelligent Multimeter
| Specifications | Range | Best Accuracy | ||
| Model | UT71C | UT71D | UT71E | |
| DC Voltage (V) | 400mV/4V/40V/400V/1000V | ±(0.025%+5) | ±(0.025%+5) | ±(0.025%+5) |
| AC Voltage (V) | 4V/40V/400V/1000V | ±(0.4%+30) | ±(0.4%+30) | ±(0.4%+30) |
| DC Current (A) | 400μA/4000μA/40mA/400mA/10A | ± (0.1%+15) | ± (0.1%+15) | ± (0.1%+15) |
| AC Current (A) | 400μA/4000μA/40mA/400mA/10A | ± (0.7%+15) | ± (0.7%+15) | ± (0.7%+15) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(0.3%+8) | ±(0.3%+8) | ±(0.3%+8) |
| Capacitance (F) | 40nF/400nF/4μF/40μF/400μF/4mF/40mF | ±(1%+20) | ±(1%+20) | ±(1%+20) |
| Frequency (Hz) | 40Hz-400MHz | ±(0.01%+8) | ±(0.01%+8) | ±(0.01%+8) |
| Temperature (°C) | -40 °C ~ 1000°C | ±(1%+30) | ±(1%+30) | ±(1%+30) |
| Temperature (°F) | -40°F~1832°F | ±(1.5%+50) | ±(1.5%+50) | ±(1.5%+50) |
| Power (W) | 2500W | ±(2%+5) | ||
| Features | ||||
| Display Count | 39999 | 39999 | 39999 | |
| Auto Range | √ | √ | √ | |
| True RMS | √ | √ | √ | |
| Bandwidth (Hz) | 100KHz | √ | √ | √ |
| Duty Cycle | 10% ~ 90% | ±(1%+30) | ±(1%+30) | ±(1%+30) |
III. Detailed Photos
