20kg 25kg 1000ton Mineral Block Briquetting Hydraulic Press Machine

Product Description

20kg 25kg 1000ton mineral block Briquetting hydraulic press machine
parameter of mineral block making press machine

parameter name	Unit	YQ32-63A	YQ32-63B	YQ32-100A	YQ32-100B	YQ32-160	YQ32-200A
Nominal force	KN	630	630	1000	1000	1600	2000
Hydraulic system maximum pressure	Mpa	25	25	25	25	25	25
Max opening height of the slide	mm	500	700	800	800	800	800
Max stroke of the slide	mm	360	400	500	500	500	400
Workbench effective area	mm	410×450	610×500	630×550	750×700	660×600	800×800
Ejector cylinder nominal force	KN	100	100	200	200	400	400
the stroke of the eject	mm	160	160	200	200	200	220
Slider speed	down mm/s	100	100	100	100	100	100
	press mm/s	5-10	5-10	5-10	5-15	5-10	5-10
	return mm/s	90	90	90	90	90	90

Characteristic of salt mineral block machine:
1, using advanced PLC hydraulic transmission technology, high technology, low failure rate, high degree of automation, high efficiency.
2, the host structure is compact, small footprint, easy to move and transport.
3, four-oriented structure, molding pressure, high density of pressed products, not broken.
4, hydraulic pump station structure design is reasonable, highly concentrated hydraulic control valve block and a unique design of the hydraulic system to make the hydraulic system perfect, and effectively achieve the continuity of normal production.
5, replace the mold can live Participation in various specifications of the salt block, weighing up to 2kg ~ 25kg, to achieve the product diversification needs and reduce investment costs.
6, the electrical control program to achieve a human-computer interaction, simple operation, convenient and quick.
7, low failure rate, heat a small, high efficiency, energy saving and durable.
mineral brick making machine Usage:
Salt brick is through the material, broken, drying, mixing, pressing, packaging and a series of process production. One of the most important aspects is to lick the salt pressure, the important equipment used is lick salt briquetting machine.
Our company produces lick salt briquetting machine is a hydraulic briquetting machine equipment with high pressure, can be one-time molding, pressing density, pressed out of the product appearance bright and clean appearance.
function of automatic hydraulic press machine

Four column hydraulic press machine	function of machine
deep drawing press machine	deep drawing tray/wheelbarrow deep drawing water/kitchen sink deep drawing Aluminum pan/pot deep drawing iron pot/basin deep drawing Vessel dish end
stamping machine	stamping shovel making machine stamping coin making machine metal sheet/tag stamping machine stainless steel utensils stamping stainless steel pipe stamping steel door stamping machine metal plate/steel hole stamping
powder forming press machine	bath bomb fizzy making Aluminum/Metal Chip Briquette melamine dinner set making machine salt lick mineral block making machine

pressed product:
500ton 10kg animal licking salt block hydraulic oil press machine Technical advantages:

1.Hydraulic hydraulic oil press machine body using high-quality carbon steel, precision welding, seam parts to take tempering to ensure that the body strength.
2.Especially the base parts, will use cast steel structure, to ensure that the hydraulic oil press machine body will never deformation.
3.Top cylinder with 45 # round steel technology, precision grinding, to achieve the work of ultra-quiet technology.
Packaging and shipping of salt mineral block brick making forming press machine:
1. inner layer is made of plastic film rust-proof packaging,
2. the embossing machine outer layer is reinforced by reinforcing the synthetic board,
3. separate container can be used.
other as requirement
