Wholesale Price CNC Circular Saw Machine with Automatic Metalsworking Sawing Machine

Wholesale Price CNC Circular Saw Machine with Automatic Metalsworking Sawing Machine

US$26,200.00-30,250.00 1 Set (MOQ)

Basic Info.

Model NO.
HD-70P Circular saw machine
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Linear Control
Control Method
Semi-Closed Loop Control
Numerical Control
CNC
Performance Classification
High-End CNC Machine Tools
Certification
CE, ISO9001:2015, ISO14001:2015
Condition
New
MOQ
1 Set
Model No
P Series Circular Saw Machine
Feed System
AC Servo Motor + Ball Screw
Circular Saw Blade Dimensions
285 X 32 X T2.0/ T1.75
Voltage
380VAC
Automatic Feed Loader
6 Meters
Cutting Material
Copper, Alloy Metal, Aluminum, Stainless Steel
Features
High Speed,Precision Cutting, Durable Quality
Shipment Way
Shipment by Vessel / Railway
Delivery Time
About 20-25 Days
Transport Package
Standard / Wooden Box Packaging
Specification
L 7180 * W 2050 * H 1790
Trademark
LING YING
Origin
Fujian, China
HS Code
8461500090
Production Capacity
300sets/Mothly

Packaging & Delivery

Package Size
730.00cm * 230.00cm * 195.00cm
Package Gross Weight
4700.000kg

Product Description

Products Photos
Product Description
About CNC Automatic High-Speed Circular Saw Machine:1. Man-Machine Interface System
The easy-to-operate intelligent automated servo system with user-friendly touch screen and PLC control system ensures the efficiency and reliability of program operation.2. One-Piece Machine Foundation
The machine foundation uses high strength casting ensures stable machine performance, high cutting efficiency,and precision. Foundation is equipped with a circulating water cooling tank, which can satisfy the needs of using water-based coolant fluid when cutting tough alloy steel materials.3. New Gearbox Structure
The innovative designed gearbox structure and configuration apply to a wide range of cutting materials.4. Remnant Management Device (Third vise)
The unique short remnant clamping structure(P series)changed from a single cylinder to double cylinder separate actions with a vertical clamping device, increase the devise stability and reliability, blade lifetime, yield rate, and saves costs.5. Innovative Automatic Feeding Device
The material feed utilizes a servo-controlled motor with ball screw and linear guiding. Specially designed structure of feed clamp yaw effectively increases the precision and reliability.6. Spray-Mist Lubricant Cooling System
The advanced MQL circular saw blade spray-mist lubricant technology can increase blade service life.

Standard

Optional
1 One set of two-axis electrical system 1 Oil mist collector
2 Hydraulic system 2 Extended feed loader
3 Automatic spray-mist lubrication system 3 Power-driven wire brush
4 Automatic material feed loader 4 Cooling water pump
5 Spiral type chip conveyor 5 Automatic chain type chip conveyor
6 Wire brush 6 Third Vise
7 One air spray gun 7 Extended carrying device for cut-off workpiece
8 Circular saw blade
9 One set of tool kits

Product Parameters
P SERIES CIRCULAR SAW MACHINE TECHNICAL DATA
Specifications HD-70P 2-Axis
CUTTING
CAPACITY
Round bar (mm) 10-70
Square bar (mm) 10-60
Trimming length (mm) 10-100
Single feed length (mm) 5-800
Remnant length (mm) 70
Perpendicularity Tolerance (mm) ±0.05/100
SAW BLADE Dimensions (mm) Φ285 x Φ32 x T2.0/t1.75
Pin hole (mm) Φ63/4/Φ11
Number of teeth (Z) 54, 60, 72, 80, 100, 120
PARAMETERS Working voltage (V) 380
Total power (KW) 14.5
Machine weight estimated (Loader included) (KG) 4500
Machine dimensions estimated (mm) L 2700 x W 2050 x H 1790
Machine dimensions estimated (loader included) (mm) L 7180 x W 2050 x H 1790
LOADER Number of pieces (P) Φ70 x 6 m x 10
Length (m) 3-6 m
* Please note: all product technical information, parameters, specifications, dimensions, and designs shown in this catalog are subject to change without prior notice. For more information, please contact Hengerda.
