Automated LDD-1/1000 Headstand Wire Drawing Machine

Product Description

Description
Description:
Vertical-type Wire Drawing Machine is mainly used for draw low, medium and high carbon steel wires and some non ferrous metal finished products. It has a heavy take-up reel, the process with both functions together which it is wire drawing and wire coiling.
The wire is drawn and then automatically coiled into the carrier below. It saves time and labors and with good efficiency.
It is convenient in unloading wires and it is an ideal equipment for processing wires of large gauge with heavy load.
Technical data
Technical data:

Model:	LDD-1/1000
Drawing wire:	25-16mm
Power:	75-90kw
Reel diameter:	1000mm
Drawing speed:	50meter/min
Machine size:	2000*2000*2500(mm)
Machine weight:	6500kgs

Company information
We are one of the Chinese professional manufacturers work at different types of Wire Drawing Machines.
The following items are the related products of the Wire Drawing Machines, kindly pls view the details as follow.
If any query you have for Wire Drawing Machines, pls don't hesitate to contact with us at any time and we are willing to further assist you!
Product picture

Warranty
One Year & Lifelong service
Within one year, if it is damaged itself, except for man-made damage, we will be responsible. Excluding electrical appliances and vulnerable parts.
One year after, our service will continue, with accessories provided by us and technical support by us, but the cost of accessories including the shipping cost by customers.
