Anti-Corrosion Aluminum Coil A3003, A3004, A3105 with Good Formability for Multiple Applications
| US$3,000.00-4,500.00 | 10 Tons (MOQ) |
Basic Info.
Model NO.
A3003, A3004, A3105
Alloy
Alloy
Certification
ISO9001, ASTM, GB, EN
Technique
Cc and DC
Grade
1000 Series and 8000series
Temper
O - H112
Surface Treatment
Mill Finish /Color Coating /Stucco Emboss/Anodize
Transport Package
as Per Client Requirement
Specification
Thickness: 0.15-10mm; Width: 20-2620mm
Trademark
Suzhou Graceland Ltd. Co
Origin
China
HS Code
76061259
Product Description
1. Aluminium coil details| Aluminium coil/Aluminium Strip | ||||
| Aluminium Alloy | Thickness (mm) | Width (mm) | Temper | |
| A1050,A1060,A1070,A1100 | 0.15-10 | 20-2620 | O,H12,H14,H16,H18,H22,H24,H26 | |
| A3003,A3004,A3105 | 0.15-10 | 20-2620 | O,H12,H14,H16,H18,H22,H24,H26 | |
| A5052,A5005,A5083,A5754 | 0.15-10 | 20-2620 | O,H12,H14,H34,H32,H36,H111,H112 | |
| A6061,A6082,A6063 | 0.15-10 | 20-2620 | T4,T6,T651 | |
| A8011 | 0.15-10 | 20-2620 | O,H12,H14,H16,H18,H22,H24,H26 | |
| Material process | both CC AND DC | |||
| Customerize size | Size can be produced as per clients requirement | |||
| Surface | Mill finish ,Color coated(PVDF& PE),Stucco Embossed ,Bright Polish ,Anodizing | |||
| Mirror,Brush,Perforated,Tread plate ,with polykraft or polysurlyn back etc | ||||
| Quality Standard | ASTM B209,EN573-1 | |||
| MOQ per size | 2 tons | |||
| Payment Terms | TT OR LC OR DP at sight | |||
| Delivery time | Within 25 days after receipt the lc or deposit | |||
| Material Quality | tension levelled,Free of defects like oil stain,Roll Marks,Waves,Dents, Scratch etc , | |||
| A+++ quality | ||||
| Application | Construction ,Building,ACP,Decoration ,Roofing,Mould,Ship Building,Lighting, | |||
| Aircraft,Oil Tank ,Truck Body, | ||||
| Packing | Standard export worthy wooden pallets,and standard packing is about 2.5 tons/pallet | |||
| coil ID:508MM | ||||
| coil weight also can be as per client's requirement from 50kgs to 8000 kgs per coil | ||||
2. production standard :as per international standard ASTM OR EN standard ,
all chemical composition ,mechanical property ,size tolerance ,flat tolerance ,etc strictly as per ASTM OR EN standard
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Other | Al | |
| Single | Total | ||||||||||
| 1050 | 0.25 | 0.4 | 0.05 | 0.05 | 0.05 | _ | 0.05 | 0.03 | 0.03 | _ | ≥99.5 |
| 1060 | 0.25 | 0.35 | 0.05 | 0.03 | 0.03 | _ | 0.05 | 0.03 | 0.03 | _ | ≥99.6 |
| 1100 | Si+Fe:0.95 | 0.05~0.40 | 0.05 | _ | _ | 0.1 | _ | 0.05 | 0.15 | ≥99 | |
| 1200 | Si+Fe:1.00 | 0.05 | 0.05 | _ | 0.1 | 0.05 | 0.05 | 0.15 | ≥99 | ||
| 3003 | 0.6 | 0.7 | 0.05~0.20 | 1.0~1.5 | _ | _ | 0.1 | _ | 0.05 | 0.15 | Remainder |
| 3105 | 0.6 | 0.7 | 0.3 | 0.30~0.8 | 0.20~0.8 | 0.2 | 0.4 | 0.1 | 0.05 | 0.15 | Remainder |
| 5005 | 0.3 | 0.7 | 0.2 | 0.2 | 0.50~1.1 | 0.1 | 0.25 | _ | 0.05 | 0.15 | Remainder |
| 5052 | 0.25 | 0.4 | 0.1 | 0.1 | 2.2~2.8 | 0.15~0.35 | 0.1 | _ | 0.05 | 0.15 | Remainder |
| 5083 | 0.4 | 0.4 | 0.1 | 0.40~1.0 | 4.0~4.9 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Remainder |
| 5086 | 0.4 | 0.5 | 0.1 | 0.20~0.7 | 3.5~4.5 | 0.05~0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Remainder |
| 6061 | 0.4~0.8 | 0.7 | 0.15~0.40 | 0.15 | 0.80~1.20 | 0.04~0.35 | 0.25 | 0.15 | 0.05 | 0.15 | Remainder |
| 6063 | 0.2~0.6 | 0.35 | 0.1 | 0.1 | 0.45~0.90 | 0.1 | 0.1 | 0.1 | 0.05 | 0.15 | Remainder |
| 6082 | 0.7~1.3 | 0.5 | 0.1 | 0.4~1.0 | 0.6~1.2 | 0.25 | 0.2 | 0.1 | 0.05 | 0.15 | Remainder |
| 8011 | 0.5~0.9 | 0.6~1.0 | 0.1 | 0.2 | 0.05 | 0.05 | 0.1 | 0.08 | 0.05 | 0.15 | Remainder |
