Interior Fast High Speed Rolling Shutters Anti Static Plastic PVC Door

Product Description

High Quality Pvc Fast Speed Roller Shutter Door
The description and specification Control systems Mitsubishi Inverter 0.75/1.5 KW, PLC and other components. Dynamical system Nord Motor, 0.75/1.5 KW, 220V/380V. Incorporating limit switches for open and close cycles
Adopt special high speed motor reducer and this drive unit can be used on manual in the event of power failure. Door Construction

Framework	Stainless Steel
Rolling shaft	In 2mm thickness cold-roll steel tube with machined blocks at each and incorporating high-speed bearing
Cross bar	In aluminum lath(Increase Wind-load ability)
Curtain	Use high-density poyester fabric

0.8 mm thickness
Self-extinguishing rate: DIN4102
Windows: Transparent PVC sheet 1.5mm thickness
Color: To be confirmed(Yellow, Green, White, Blue, Orange, Red, Grey as optional) Command system Push Button Safe system Photoelectric sensor (Door will not close if there is people or other object under door)
Emergency stop protection
Safety Edge Bottom Technical Parameter Power supply: 100V AC-15% to 250 V AC+10%; 50/60Hz
Power consumption: Max -250W
Opening & Closing speed: 0.7~1.2m/s
Opening & Closing frequency: 1000-1500 cycles/day
Wind load: 15 m/s
Working temperature: -10ºC to +50ºC Nord motor data parameter 0.75 KW Rating: S1 IP: 55 Ins: F
V Hz A r/min
220△ 50 3.80 1380
380Y 50 2.20 1260
CosΦ: 0.73
Speed ratio: 10.91
Brake Voltage: 220V
BrakeTorque: 10
Torque: 50 NM
Application:
Certification
FAQ
What is the delivery time? A: 20 days for the standard colors and 30 days for the customized. Also it depends on the specifications and quantity each order. Shipment time depends on the location of our customers.
What is your payment items? A: Normally we accept 30% for deposit by T/T and the balance would be arranged before delivery. If you have any other suggestion, please contact with us.
Can we place one or two sets for trial? A: Yes of course, this is the better way of quality check. Also if you don't required one whole set, we have small sample in stock as well, it is free of charge, you just need to handle with the freight. It is a good way to show the sincerity for both of us.
How can I know the price exactly? A: The price is based on your specific requirements, it is better to provide as much as possible information such as color, size, quantity, market location, sales patterns, all of these would be of help us to quote the exact price.
Can I order components instead of the full set of door? A: Yes, as a factory we welcome business clients purchasing components of the door, such as panels, hardware's, motors, etc., to maximize the advantage of our mutual parties.
