Automatic Knitted Woven Fabric Edge Double Folding Sewing Machine

Automatic Knitted Woven Fabric Edge Double Folding Sewing Machine

US$14,000.00
1-2 Set
US$12,000.00
3-4 Set
US$11,000.00
5+ Set

Basic Info.

Model NO.
S320
Condition
New
Certification
GS, RoHS, CE, ISO9001
Automatic Grade
Automatic
Application Place
Factory
Applicable Thickness
Thick Material
Thread Number
Three Threads
Needle Number
Six Needles
Head Number
Single
Material
Stainless Steel
Fabric Width
2800mm
Fabric Sensor
Automatic Stop
Air Selvedge
Unrolling
Automatic System
Automatic Control Middle Fabric Position
Sewing Stitch
5 up to 12mm Adjustable
Working Speed
38mt/Min
Fabric Tension Control System 1
Adjustable Fabric Tension in Sewing Phase
Fabric Tension Control System 2
Adjustable Fabric Tension in Doubling Phase
Elastic Seam
Avoiding Breakdown Thread
Use
Knit Fabric
Fabric Doubling
Tubular Sewing
Frame
Strong Frame
Tension Roller
Control Fabric Tension
Quality
High Quality
Transport Package
Pallet
Specification
Max 2800mm
Trademark
JTFTEX
Origin
China
HS Code
8205510000
Production Capacity
1000set/Year

Product Description

Product Description
Especially with knit fabrics(lycrafabric, jersery etc).
This machine allows to dye the fabrics with a final process quality impossible to have with the direct dyeing of the fabric in open rope.
Technical Features:

The high speed sewing machine is suitable for the viscose, the nylon, the polyester fabric.
Fabric enter by open-width method, maximum width up to 2800mm
Equip with four "Herringbone" rollers.
Fabric leading rollers wrapped by PVC, actuated by the digital frequency changer.
Equip with tension roller, control the fabric tension.
Equip with 2 sets of central ajustment device, use to adjust the fabric.

Stitching machine unit
*Sensors of the fabric edge position
*Automatic movement of the stitching forward- backward according the fabric width
*Automatic fabric edge following and automatic positioning
*Easy accessibility for facilitate the job to the operator
*Adjustable stitching distance from the edge without stop the machine
Detailed Photos
Production Process

FAQ
Q: Why Choose Our Company?
Jingtian Textile Machinery Co., Ltd. (founded in 1991) is a key backbone production enterprise in China's textile machinery manufacturing industry. It has a long history and experience in independent development and production of textile machinery products. It has a first-class R & D center and scientific and technological development team. It is an enterprise that has passed ISO9001 quality system certification earlier in the industry. At present, the company has 20 subsidiary companies with nearly 300 employees. Diversified products, standardized corporate governance structure and flexible business mechanism have injected new vitality into the development of the company.
Q: How's the after-sale service?
We offer engineers available to service overseas under merchandiser's supervision and translation.
Q: Are you available for on-the-spot invitation? We do welcome our new and old friends come here to have a visitation. Besides, we would send you our exposition and relative information to promote a face-to-face meeting if you'd like to.
Q: Is the price offered changeable? We offer reasonable price for every client, and the price is changeable according to purchasing amount.
Q: How about the quality? We have an intelligent manufacturing system.
Q: Are you a manufacturer or Trade Company? We are a professional manufacturer holding our own International Trade Department, for that we can better understand customer's needs and offer a reasonable price.
Q: Product /Quality Guarantee and After Sale Service? 1 year warranty for the International standard. We are work online 24 hours. If you have any questions about our machine you can contact us.
Q: One-stop Service: We have R&D department including more than 100 engineers which are improving and enlarging our supply range.
Q: Certification?
JingTian is an ISO9001, ISO14001 company. The products are designed to meet the technical standards of 3C and CE. All the products are certified by the Industry Administration Authority. JINGTIAN will continue to strive to be a stronger leader in the global market of Cotton machinery and Spinning machinery. Contact Us
