PP PE Film Two Steps Pelletizer Granulation Production Machine
| US$15,000.00-70,000.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
SJ45, 55, 65, 75, 90, 120, 150
Automation
Automation
Computerized
Computerized
Certification
ISO9001:2008, CE, TUV
Warranty
1year
Electrical Appliances
ABB, Omron, Rkc, Shneider
Delivery Conditions
Fob CIF CIP
Processing Period
40 Days
Delivery Period
30days
After-Sales Service
Send Engineers Install and Test Machine
Technical Support
Permanent
Line Diamision
10m*3*3m
Line Weight
5-12t
Output
900-1000kg|H
Transport Package
Stretch Film and Wooden Pallet, Wooden Packing
Specification
According to customer requirements
Trademark
Sincere Machinery
Origin
Qingdao, China
HS Code
8477200000
Production Capacity
50 Sets\Year
Product Description
PP PE PMMA PET Recycling granulation Machinery pelletizing machine.Plastic Recycling Machine.
PP PE Film Two Steps Pelletizer Production Line Machine.
This pelletizing extruder has the special screw design and different configuration, it is suitable for the recycling and pelletizing of raw materials such as PP, PE, PET, PS, ABS, PA, PVC, PC, POM, EVA, PMMA and the pelletizing of the raw materials with different colors. The gearbox is high torque designed which attains the functions of low noise and stable operation. The surface of the screw and barrel has been special treated so that the screw and barrel are wearable, they can have a very good plastification and mixing effect and the production capacity is high. The extruder has the vacuum vented design which can exhaust the vapor or gas during the production, so that the output can be more stable and the pellets are more dense.
| Model | Screw dia. (mm) | L/D | Screw speed max. (rpm) | Main motor power (kw) | Output (kg/h) |
| XSSP45 | 45 | 25-36 | 20-120 | 5.5-11 | 18-40 |
| XSSP65 | 65 | 25-36 | 20-120 | 15-37 | 40-90 |
| XSSP90 | 90 | 25-36 | 20-95 | 37-75 | 100-250 |
| XSSP120 | 120 | 25-36 | 20-80 | 55-110 | 250-380 |
| XSSP150 | 150 | 25-36 | 20-80 | 110-160 | 300-450 |
| XSSP180 | 180 | 25-36 | 20-80 | 180-250 | 400-650 |
| Model | Screw dia. (mm) | L/D | Screw speed max. (rpm) | Main motor power (kw) | Output (kg/h) |
| SJ-45 | 45 | 25-36 | 20-120 | 5.5-11 | 18-40 |
| SJ-65 | 65 | 25-36 | 20-120 | 15-37 | 40-90 |
| SJ-90 | 90 | 25-36 | 20-95 | 37-75 | 100-250 |
| SJ-120 | 120 | 25-36 | 20-80 | 55-110 | 250-380 |
| SJ-150 | 150 | 25-36 | 20-80 | 110-160 | 300-450 |
| SJ-180 | 180 | 25-36 | 20-80 | 180-250 | 400-650 |
