High Efficient Gravel Crushing Impact Breaker (PF1010) for Sale

Product Description

High Efficient Gravel Crushing Impact Breaker (PF1010) For Sale
PF series impact crusher impact breaker is the ideal equipment for intermediate crushing with the compressive strength of stones/ores no more than 350Mpa. It is widely used for crushing and shaping rock/ore in mining, building materials, expressway/railway construction, metallurgy, chemistry industries.
The final product in excellent cubic shape is improved, needle-like and flake-like shape products can be reduced, and energy consumption can be reduced 40%.
Impact breaker working principle: Impact crusher has two series: two-cavity and three-cavity impact cusher. It is one kind of crushing equipments using impact energy to crush material driven by motor.When the materials get into the area where the plate hammer effects, by whose high speed impact function, the crushed materials are thrown to the impact device above the rotor continuously, and then they are rebounded from the impact liner to the effect area of the blow bar to be crushed again. The materials are repatedly crushed from big-size to small-size in the impact cavity. The process goes on until the materials are crushed to the required size and then discharged from the down part of the machine.
Gravel Impact breaker features:
Final products in cubic shape.
High process capacity,
Low energy consumption,
Stable structure,
Adjustable discharge opening,
Convenient operation and maintenance.
Gravel impact breaker rotor part :
Gravel Impact Breaker main technical parameters:

Model	Specification (mm)	Feeding size(mm)	Max feed size(mm)	Capacity (t/h)	Motor power(kw)	Weight(kg)
PF-0607	644*740	320*770	100	10-20	30	10216
PF-0807	850*700	400*730	300	15-30	30-45	11138
PF-1008	1000*800	400*830	300	30-50	37-55	12206
PF-1010	1010*1050	400*1080	350	50-80	55-75	13138
PF-1210	1250*1050	400*1080	350	70-120	110-132	15200
PF-1212	1250*1250	400*1300	350	100-150	132-160	17025
PF-1214	1250*1400	400*1430	400	130-180	160-200	19015
PF-1315	1320*1500	860*1520	500	160-250	180-260	24600
PF-1320	1320*2000	860*2030	500	300-350	300-375	29800
PF-1520	1520*2000	980*2980	700	400-500	400-480	38600

Gravel Impact breaker Package and shipping:
Our service:
Hengxing equipment can provide turkey service for customers, such as engineering consultation, engineering design, equipment manufacturing, packing & transportation, installation & commissioning personnel training etc.
About Spare Parts
Hengxing equipment will be dedicated to provide our customers with genuine spare parts with high quality. With our technological advice, the life cycle of your machine can be prolonged and sustained significantly with high effectiveness.
About Training
Hengxing equipemnt could offer excellent facilities and comfortable environment and training services to different customers. The training should include product training, safety training, operation training, maintenance know-how, technical know-how training, and regulations training, etc. All of the training is customized to fulfill every customer's expectations. Training programs can be conducted in our workshop, or at customer's site.
About Installation and Commissioning
Hengxing equipment are able to guide the overall installation of whole set production line, including crushing production line and cement equipment production line, etc., which will allow you to start the normal operation of equipment immediately. After installation,we will make inspection of the whole machine commissioning and operation condition and provide you testing data report of installation.
Why choose us?
1We have special Machinery Research Institute
2Our product quality has been in line with international level
3Our products are exported to ninety countries and regions
4We are dedicated to providing best solutions and turnkey projects
5A variety of honor to witness, 100% professional
6We provide you with all-round, one stop services
