Dimpled Drainage Sheet Machine, Drainage Geotextile Sheet/HDPE PP Dimple Drainage Sheet Production Line
| US$120,000.00-150,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
DL-2300
Plastic Processed
HDPE
Product Type
Extrusion Molding Machine
Feeding Mode
Multiple Feed
Assembly Structure
Integral Type Extruder
Screw
Single-Screw
Engagement System
Full Intermeshing
Screw Channel Structure
Deep Screw
Exhaust
Don′t Exhaust
Automation
Automatic
Computerized
Computerized
Applicable Material
HDPE, MDPE, LDPE, LLDPE
Working Width
2000-6000mm
Thickness Range
0.5-2.0mm
Extrusion Capacity
350-500kg/H
Speed
1-5m/Min
Size
20000×6000× 4000mm
Weight
25000kg
Transport Package
in Nude
Trademark
CANDID
Origin
China
Production Capacity
10 Sets Per Year
Product Description
FINAL PRODUCTComponents and specifications
| No. | Qty. | Specification & description | Remark |
| Main Unit | |||
| Feeding | |||
| 1 set | Helix Loader& Hopper | ||
| Capacity: Continuous feeding | |||
| SINGLE SCREW EXTRUDER | |||
| 1 set | Single Screw Extruder diameterĪ¦150 L/D ratio 35:1 | ||
| Screw and barrel, origin Zhoushan,Zhejiang, China | |||
| Screw, 38CrMoAl, nitridation and polishing | |||
| Barrel: 38CrMoAL,nitridation treatment, water cooling in feeding parts | |||
| 1 set | Frequency converter | ||
| 1 set | Motor power 160kw | ||
| 1 set | ZLYJ375 Gear box,high torque, low noisy and hard gear face, with oil cooling system | ||
| 2 sets | Pressure sensors | ||
| 1 set | Melt pump 350CC 18.5KW |
| Each set in front and back of pump | |||
| 1 set | Screen changer | ||
| Hydraulic cylinder control, quick change ans easy operation. | |||
| 1 set | Flat head die (T Die) 2300mm | ||
| With rack cavity and compounding die orifice to make film flat and it is easy to be adjusted. It can be adjusted in a large range and produce products of various thickness. Material:Stable alloy tool steel with the tempering treatment, less change in shape after heating, inner surface polished, hard chrome plating and abrading treatment. | |||
| Heating zone: Stainless steel heating tube; | |||
| Width adjustable by using deckles | |||
