Open TBR Tyre One Stage Building Machine Single Stage TBR Tire Building
| US$1.00-111,111.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
1
Certification
CE, ISO, Ghost
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Customized
1
1
11
11
111
111
1111
1111
Transport Package
Wooden Case
Specification
standard container
Trademark
FINEYEAR
Origin
China
HS Code
84778000
Production Capacity
1000 Sets Per Year
Product Description
Three-drum All-steel Radial Truck Tire Building Machine 1.UsesFor one-time forming of all-steel radial truck tires.
2. Tire Type
R17.5-24.5
3. Capacity: 90 - 100 strips/shift
4. Controls
Mitsubishi Q series PLC, mobile CPU, CC-LINK fieldbus, and SSCENT servo system; can also use Siemens, AB, Rexroth, or other PLC and bus form, depending on customer's needs.
5. Main Features and Technical Parameters
Molding drum: mechanical down assembly, servo motor control.
Tire casing drum: servo motor control, accurate, stable speed, position, vacuum absorb.
Belt drum: servo motor control.
Tire casing transfer ring: servo motor drive, linear guide positioning, synchronous belt transmission.
Belt transfer ring: servo motor drive, ball screw transmission.
Feed frame: various, consisting of relevant unwinding, centering device, automatic length set, cutting and fitting device.
Parameter
| Type | X(S)M-25 | X(S)M-50 | X(S)M-80 | X(S)M-90 | X(S)M-110 | X(S)M-160 | X(S)M-180 | X(S)M-250 | X(S)M-270 | X(S)M-300 | X(S)M-370 | X(S)M-420 | |
| Total volume of mixing chamber(L) | 26.5() 2 wings | 50() 2 wings | 80() 2 wings | 90() 2 wings | 110() 2 wings | 147() 4 wings | 166() 4 wings | 253() 2 wings | 250() 4 wings | 280() 4 wings | 395() 4 wings | 425() 4 wings | |
| Working volume of mixing chamber(L) | 20 | 37.5 | 60 | 67.5 | 82.5 | 110 | 124.5 | 140 | 188 | 210 | 296 | 319 | |
| Speed of rear rotor(r/min) | 6-60 | 4-40 | 4-40 | 4-40 | 4-40 | 4-40 | 4-40 | 20() (Front rotor) | 4-40(6-60) | 4-40(6-60) | 6-60 | 6-60 | |
| Speed ratio of rotors(r/min) | 1:1.15 | 1:1.15 | 1:1.15 | 1:1.15 | 1:1.15 | 1:1.16 | 1:1.16 | 1:1.16 | 1:1.17 or 1:1 | 1:1.17 or 1:1 | 1:1.15 or 1:1 | 1:1.15 or 1:1 | |
| Pressure of compressed air(Mpa) | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | |
| Consumption of compressed air(m³/h) | ~70 / Hydraulic | ~80/Hydraulic | ~100/Hydraulic | ~100/Hydraulic | ~230/Hydraulic | ~300/Hydraulic | ~300/Hydraulic | ~120/Hydraulic | Hydralic ram | Hydralic ram | Hydralic ram | Hydralic ram | |
| Pressure of cooling water(Mpa) | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | |
| Consumption of cooling water(m³/h) | ~10 | ~15 | ~25 | ~25 | ~35 | ~45 | ~50 | ~23 | ~100 | ~100 | ~150 | ~150 | |
| Driving motor power(kw) | 90 | 110 | 220 | 220 | 280(315) | 600 | 720 | 280(315) | 1250(1500) | 1250(1500) | 2500 | 2500 | |
| Dimension(mm) | L | 4460 | 5560 | 5800 | 5800 | 6620 | 8000 | 8500 | 7100 | 8700 | 8700 | 10800 | 10800 |
| W | 3225 | 2510 | 2560 | 2560 | 2850 | 3330 | 3400 | 3905 | 4320 | 4320 | 4960 | 4960 | |
| H | 3200 | 3200 | 4200 | 4200 | 4400 | 5260 | 5350 | 4953 | 6160 | 6160 | 7040 | 7040 | |
| () Weight(Except main motor)(t) | ~7 | ~14 | ~22 | ~22 | ~26 | ~36 | ~39 | ~35 | ~50 | ~54 | ~76 | ~76 | |
