Pet Bottles and Flakes Recycling Line to Recycle Plastic Water Bottles

Product Description

Product Description
PET plastics crusher washing line plastic bottle washing line
This PET bottle recycling line is mainly used to recycle waste PET bottles to make PET flakes ,mainly inclue de-baling machine, conveyor belt, label remover, sorting system,crushing, floating washing tank, hot washing tank, frication washing, dewatering &hot air drying system, label separator a,with the above machines and process can easily to remove the labels, caps, rings, glue, dirties and other impurities, finally you will produce to clean PET flakes.It can reach achieve request of "Bottle to Bottle" ,"Bottle to Fiber product"
We can make recycling line according to different customize requirements!
Our complete PET bottle washing line provide fully automated, turnkey solution, the turnkey PET bottle washing line consists of a series of our plastic recycling machines, any auxiliary machine you need, please contact us at will.

Product Parameters
Technical dates

Capacity	Installation power	Area required	Labor required	Water supply
500kg/h	155kwh	35*10*6m	5-6	3t/h
1000kg/h	285kwh	50*12*6m	6-8	4t/h
1500kg/h	350kwh	70*12*6m	6-8	5t/h
2000kg/h	485kwh	80*15*6m	9-10	6t/h
3000kg/h	690kwh	100*18*7m	10-12	7t/h

Detailed Photos
1)Label remover
2)Crushing machine
3)Hot washing machine
4)Cold floating washing tank
5)Dewatering machine
Packaging & Shipping
