Automatic Hydraulic Surface Grinder Price for Sale
Basic Info.
Model NO.
MY1230
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Cylindrical Grinder Type
Universal Cylindrical Grinder
Precision
Precision
Certification
CE, ISO 9001
Condition
New
Table Size
480X200
Table Travel
530X220
Number of T-Slot
1X14
Speed of Woking Table
3-20m/Min
Max,Distance From Spindle to Table
450mm
Wheel Speed
2850rpm
Wheel Size
200X20X31.75mm
Hydraulic Station Motor
1.5kw
Coolant Pump
0.4kw
Working Pressure
3MPa
Transport Package
Wood Case
Specification
M820
Trademark
UNI-TECH
Origin
China
HS Code
8460190000
Production Capacity
100PCS/Month
Product Description
Automatic Hydraulic Surface Grinder price for sale| Model | Units | MY820 | MY1022 | MY1224 | MY1230 | |
| Table Size (L×W) | mm | 480*220 | 540*250 | 600*300 | 750×300 | |
| ( L×W) | ||||||
| table travel | mm | 530x220 | 560x260 | 630x320 | 780x320 | |
| speed of working table | m/min | 3-20 | ||||
| Distance From Spindle to table | mm | 450 | 450 | 530 | 530 | |
| Table Slide way | / | V-type rail with Steel-ball | Double V-type rail | |||
| V-type rail with Steel-ball | kg | 200 | 200 | 250 | 250 | |
| Number of T -Slot | mm*n | 14*1 | ||||
| Cross Feed On Handwheel | mm | 0.02/Graduation 2.5/revolution | 0.02/Graduation 4/revolution | |||
| Vertical Feed On Handwheel | mm | 0.01/Graduation 1.25/revolution | 0.01/Graduation 2/revolution | |||
| Wheel Size (dia.×width×bore ) | mm | 200*20*31.75 | 250*25*76.2 | |||
| wheel Speeds(50HZ) | rpm | 2850 | 2450 | |||
| Spindle Motor | kw | 1.1 | 1.5 | 2.2 | 2.2 | |
| Hydraulic station motor | kw | 1.5 | 1.5 | 2.2 | 2.2 | |
| Rapid Up and down Motor | w | 120 | 120 | |||
| Working Pressure | Mpa | 3 | 3 | 4 | 4 | |
| Max.Capacity | L/min | 18 | 18 | 20 | 20 | |
| Fuel tank capacity | L | 80 | ||||
| Packing Size (L×W×H) | mm | 1700*1200*1940 | 1300*1620*1900 | 1960*1640*2020 | 1960*1640*2020 | |
| Net,Gross | kg | 750/850 | 900/1000 | 1300/1430 | 1400/1530 | |
Our Services
1. Your inquiry and email will be replied within 24hours.
2. If you need to develop products with your own specification, we can help you to work it out.
3. Always be honest, never lie to customer, and never declare anything we don't have.
4. Customer First:,we offer best Quality and Service!
FAQ
1. Payment Method:
30% deposit T/T in advance, rest against the copy of B/L or before delivery.
2. Delivery Time:
one week
3. MOQ:
1 set machine.
If you need machine with your own specification, logo, packing, etc, please negotiate with us.
4. Shipping:
For machine: Usually by sea;
For documents: by international express, eg. DHL,TNT or EMS
