Industrial Wood Double Side Thickness Planer

Industrial Wood Double Side Thickness Planer

US$1,530.00-2,200.00 1 Set (MOQ)

Basic Info.

Model NO.
WS204
Working Depth
100-200mm
Working Width
200-400mm
Drivetrain
Worktable Elevating Drivetrain
Enter Method
Mechanical
Motor Power
5-10Kw
Cutter Shaft
2
Spindle Speed
<5000rpm
Process Type
Light Processing
Certification
ISO
After-sales Service
12 Month
Model
204
Max Planing Width
400mm
Max Press Thickness
130mm
Motor
5.5kw
Voltage
380V
Transport Package
Customized
Specification
Customized
Trademark
Customized
Origin
China
HS Code
8465920000
Production Capacity
200 Sets Per Year

Packaging & Delivery

Package Size
150.00cm * 80.00cm * 18.00cm
Package Gross Weight
650.000kg

Product Description

Product Parameters
Double Side Planer Thicknesser
Model WS204 WS206
Max.planing width 400mm 600mm
Max.press thickness 130mm 130mm
pressure gauge 5mm 5mm
Max.cutting length 200mm 200mm
Max.cut surface knife 4mm 4mm
Bottom knife cutting quantity 2mm 2mm
Motor power 5.5KW 380V 4KW*2 380V

Related Machines
Single Side Thickness Planer
Model 104 106
Max .planning width 430mm 630mm
Max .pressing thickness 200mm 200mm
Min. pressing thickness 5mm 5mm
Min .planing depth 5mm 5mm
Spindle speed 5600r /min 5600r /min
Min .planing length 200mm 200mm
Feeding speed 9.10m /min 9.10m /min
Motor power 4kw /380v 5.5kw /380v
Overall Dimensions 900*930*1300mm 900*1130*1300mm

Belt Feeding Single Side Planer
Model 104A
Max .planning width 430mm
Max .pressing thickness 200mm
Min. pressing thickness 5mm
Min .planing depth 5mm
Spindle speed 5600r /min
Min .planing length 200mm
Feeding speed 9.10m /min
Motor power 3kw /380v

Single Side Heavy Duty Thicknesser Planer
Model 1013 1016 1020
Max.sawing width (MM) 1300 1600 2000
Max.sawing thickness (MM) 200 200 180
Max.planing quantity (MM) 5 5
Min.planing length (MM) 270 270
Saw shaft diameter (MM) 140 140
Spindle speed R/Min 3500 3500
Main Motor KW 13 15 13
Feeding motor KW 3 1.5
Lifting motor KW 0.75

Four Side Planer
Max.working width 400mm
Max.working thickness 20-120mm
Max.planing depth 5mm/3mm/5mm/5mm
Arbor speed 8000r/min
Arbor motor power 5.5KW 380V
L&R spindle speed 7000r/min
L&R spindle motor 3KW/3KW
Feeding speed 9.2m/min/7.5m/min

4023 Four side moulder
Number of spindles 4
Processing width 20-230mm
Processing thickness 10-125mm
Feeding speed 5-20m/min
Feeding power 2.2kw
Bottom knife motor power 4kw,
Power of the left and right spindles 5.5kw, 5.5kw
Total weight 2500kg
Upper knife motor power 7.5kw
Cross beam lifting and lowering power 0.75kw
Total power 25.45kw
Air pressure 0.3-0.4mpa

6023 Four side moulder
Min processing length(continuously feeding) 500mm
planing width 120MM 20-230mm
Planing thickness 10-150mm
Feeding speed 5-30m/min
Max Up/Down (Front table) 5mm
Max Moving Amount (Front table guider) 5mm
Feeding Wheel Diameter 140MM
Spindle speed 6000RPM
Spindle Movement(Front Bottom 40mm) 10MM
Vertical Spindle Movement(Left/Right 40MM) 30MM
Spindle Movement(Top 40MM) 20mm
Knife Diameter(Top spindle) 145MM
Knife Diameter (Front Bottom) 120MM
Knife Diameter (Left/right Vertical) 145MM
Motor Power (First Top Spindle) 11KW
Motor Power(First Bottom Spindle) 7.5KW
Motor Power(Left Vertical Spindle) 7.5KW
Motor Power(Right Vertical Spindle) 7.5KW
Motor Power(Second Top Spindle) 11KW
Motor Power(Second Bottom Spindle) 11KW
Feeding power 5.5kw
UP/down motor 0.75KW
Total power 61.75kw
Air pressure 0.25-0.3mpa
Pressure Air Demand 0.1M3/Min
