Fabric Napping and Pilling Tester GB/T 4802.1

Product Description

Fabric Napping and Pilling Tester YG502
Aplication
Drapability Testing Machine is used to test the dynamic and static drape performance (drape coefficient, liveness rate, surface ripple and aesthetic coefficient) of various fabrics.
Standards
GB/T 4802.1
Features
** The instrument adopts touch screen display, with simple interface and easy operation.
** Linear guide sliding, DC motor drive, PI control algorithm speed, make the instrument run smoothly, low noise.
** The operation of the instrument is stepless speed regulation, and the customer can set the speed freely according to the test requirements.
** The user can set the required working mode according to the needs
Counting mode: times counting, time counting;
Count mode: add count, subtract count.
Self editing mode: there are five groups of self editing settings
** The self editing mode can set the count value of pilling and pilling at the same time, and it can be switched in the test interface without repeatedly setting the count value.
Specifications
** Movement track: circle track with diameter of 40mm
** Adjustable height of brush: 2-12mm
** Sample pressure:
Chemical fiber fabric pressure 590cN
Combed wool fabric pressure 780cN
Carding fabric pressure 490cn
** Sample specification: φ 112.8mm (100cm2)
** Speed range: (40-80) ± 2r / min
** There are two counting methods
Counting times: 1-999999
Time count: 1-999999min
Models YG502
Power/Air AC220V 50Hz 200W
Demensions 560*350*380mm
Weight 30kg
