300kg/Hr PE PP Film Woven Bags Friction Crushing Washing Recycling Squeezer Drying Line

Product Description

300kg/hr PE PP Film Woven Bags Crushing Washing Recycling Squeezer Drying Line

Product Description
By our PP PE film bag washing squeezing recycling machine,the waste PE film/PP woven bag could be crushed,fully washed and squeezing drying. The final film flakes humidity will be lower than 3%.
After getting washed,we could put the dry film into our PP PE film pelletizing machines to make granules.
Features of 300kg/hr PP PE film recycling line:
1.Heavy duty crusher/grinder, maximum to get 3000kg/h for LDPE film.
2.High efficiency paper removing system can completely separate paper stickers tags from PE LDPE LLDPE film.
3.Multiple-Channels washing tank design,best washing effect.
4.Squeezer application on drying, ensure moisture 3%.
5.High output, max 2000kg/h-3000kg/h
RETECH also supply plastic film pelletizing granulation machines,just you need tell us what is the capacity you need to get,then we will send a offer quickly.
Equipment list:

No	Equipment name	Quantity	Power
1	Belt conveyor	1	2.2kw
2	Wet Crusher	1	55kw
3	Double screw conveyor	1	2.2kw*2
4	Film floating washer	1	2.2kw*3
5	Screw conveyor	1	4kw
6	High speed friction washer	1	30kw
7	Screw conveyor	1	4kw
8	Squeezing dryer machine	1	110kw
9	Storage hopper	1	2.2kw*2
10	Electrics	1

Detailed Photos
Product Parameters

Model	Power	Water Consumption	Capacity
RFW300	85kw/h	4-5 t/h	300kg/h
RFW500	160kw/h	8-10 t/h	500kg/h
RFW1000	320kw/h	10-12 t/h	1000kg/h
RFW	425kw/h	15-20t/h	2000kg/h

Certifications
Packaging & Shipping
Company Profile
ZHANGJIAGANG RETECH MACHINERY CO.,LTD is a leading manufacturer for plastic recycling machines. We have more than 15 years experience focused on our filed and exported more than 30 countries and areas.
Our mainly products are as below:
PP PE film washing line
PET bottle washing line
HDPE bottle/pipe washing line
PP PE film granulating line
HDPE/PP rigid flakes granulating line
Our Advantages
FAQ
Q&A about recycling machines:
1. What is the function of the PE PP film washing recycling machines?
The PE PP film washing recycling machinery is used to recycle and process the PE agriculture film, PE bags, shopping bags, beverage bags, PP woven bags, and some other soft material etc…
2. Where does it collect the waste material for the PE PP film washing recycling machines?
The waste mater is gotten mainly from agriculture film, city rubbish and plant in bale package or separated. They are with much dirties, such as the earth, soil, sand, stone, glue, grass, oil, and some other dirties.
But by our many years experience to manufacture the washing line, we can promise to wash the material clean enough to take the washed material into the extruder to make granules. We have our special design to guarantee this point.
3. What are main parts of the PE PP film washing recycling machines?
The following is a standard structure of the PE PP film washing recycling machinery:
Belt conveyer--- crusher with water--- screw conveyer--- floating washer--- screw conveyer--- high speed friction washer--- high speed friction washer--- screw conveyer--- horizontal centrifugal dewatering machine (or squeezer)--- drying system 1--- transition hopper--- drying system 2--- storage silo--- operating panel
The up is a standard structure of the line, we can adjust it to remove some parts or add some parts due to the situation of the material or customers' requirements.
4. What capacity of the PE PP film washing recycling machinery?
300-1000kg/h for single washing line
5. What power of the PE PP film washing recycling machines?
150kw~480kw
6. How much water does it need of the PE PP film washing recycling machines?
3~8T per hour
7. How large space does it need for a PE PP film washing recycling machines?
100~400 square meters, the whole line could be installed by straight, "L" shape or "U" shape. We could design how to instal the machines due to the space of your factory.
8. What is the condition of the final products from the PE PP film washing recycling machines?
The size of final flakes will be 50~100mm, and final moisture level of film flakes will be lower than 5%.
The PP PE flakes can be taken directly to the granulating/pelletizing line to make granules/pellets.
9. What is material of the PE PP film washing recycling machines?
The parts contacted with water are made of stainless steel SUS 304 or customized.
10. What certifications do you have for the PE PP film washing recycling machines?
We have CE and ISO9001 certification for the entire PE PP film washing recycling machines.
