Popular Price Power Steering Hose Hydraulic Hose Fitting for Crimping Machine
Basic Info.
Model NO.
MJ52
Certification
CE
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Horizontal
Model No
Mj52
Name
Hydraulic Hose Crimping Machine
Crimping Range
1/4-2" 6-51mm
Max Opening
116mm
Power
3kw/4kw or Customize
Scale Accuracy
0.01mm
New Weight
260
Free Dies
10sets
Dies Number
15 19 23 26 31 36 41 47 55 63or Customize
Dimension
L 750*W520*H980
The Max Open Toleranc
+/- 30mm
Oil Pump
2.5L, 5lor Customize 10L
Voltage
220V /240V/380V/415V or Customize
Crimping Force
560t
Operational Way
Foot Control, Button Control, Automatic
Transport Package
Wooden Case
Specification
L 780*W 500*H 1000mm
Trademark
MJ hyd
Origin
Tianjin
HS Code
8479819000
Production Capacity
500sets Per Month
Packaging & Delivery
Package Size
75.00cm * 52.00cm * 98.00cm
Package Gross Weight
260.000kg
Product Description
MJ52 Hydraulic Hose Crimping Machine 1/4-2inch 3-8inch hydraulic pipe press Ferrule crimper pressing high pressure hose crimping machine for sale price| crimpi inner diameter | 1/4-2inch(6-51mm) | Oil pump | 2.5L/5L or customize 10L |
| motor power | 3KW or customize 4KW | scale accuracy | 0.01mm |
| max opening | 115mm | dies molds | 10 sets or customize |
| Package dimension | L 780*W 500*H 1000mmm | Gross weight | 260KG |
| dies mould | 10sets | Dies number | 15 19 23 26 31 36 41 47 55 63 |
| Good factory price hydraulic hose crimping machine 1. The double cone structure of the machine head presses out pipes that are more uniform and durable 2. The oil pump is a HONOR brand imported from Taiwan 3. The oil seal imported from Taiwan, Dingji brand, is durable and not prone to oil leakage. Most machines will experience aging and oil leakage after prolonged use 4. The higher the precision of fine-tuning, the more precise the pipe is clamped out, and the FINNPOWER brand fine-tuning is universal 5.3.7KW motor is not 3KW |
| Custom service: according to your stuff pressed, make suitable dies pattern and machine for you Options: In addition to the standard die sets, a wide range of special die sets for different diameters, lengths and forms is available Because the number of pictures displayed is limited, if the picture above does not find the model you want to press, please contact customer service immediately, and we will give you the most professional answer Die mold: different pressing product need different die mold. Like air suspension ring , air conditioner hose , brake hose , hydraulic hose , cable ,steel pipe , so you can tell us what you need to crimp , then we make dies mold for your products . |
Main product
Company Profile Oriental Mj Hydraulic Machinery (tianjin) Co., Ltd. Oriental MJ Hydraulic Machinery(Tianjin)Co.,ltd has always been committed to the research and development of Hydraulic hose&
Tubing Processing Equipment, high and low pressure rubber hose, fitting joints, etc.
History of more than 18 years, offering customized solutions gained from research, precision and quality.
The main equipment are manufactured by germany and Japan,specifically set up for this purpose, making it a critical piece to MJhdraulic consistent quality.
Certifications
FAQ
| Q: Are you a factory? A: Yes, we are a factory. We manufacture all our products and also manufacture for trading company. We can offer factory direct price to you. Q: Can you produce product with my own brand? A: Yes, it's available except famous brand which are not allowed. Q: Can you customize 415 V voltage or 110V? A: Yes, we can customize the voltage according to your demands, like 110V 240V 415V and so on. Q: Delivery time A: For most models of our factory machine, they are in stock, and can delivery within 24 hours once receive the payment. Q: How long does the warranty? A: For the warranty, it is 3 years, during this time, our factory have promise to provide the free spare parts to customer. Q: How to pay? A: You can pay by T/T, credit card, western union, L/C etc. |
