Tat-760 4 Axis CNC Engraving Milling Machines
| US$18,000.00-22,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
TAT-760
CNC or Not
CNC
Transport Package
Wooden Package
Specification
760
Trademark
TALENT
Origin
Suzhou, China
HS Code
8401200000
Production Capacity
20PC/Month
Product Description
TAT-760 4 Axis CNC Engraving Milling MachinesThe imported control system and its matching servo driver and motor are used to realize three axis linkage. It is suitable for the parts with proper batch, which are complex, many processes, high precision requirements, need various types of ordinary machine tools, various cutting tools and tooling, and can be processed after many times of clamping and adjustment. Main processing special-shaped parts, plates, sets, plate parts. It is widely used in electronic, mechanical, automotive, aircraft, aerospace, ship, national defense and other fields of products.
TAT-760 4 Axis CNC Engraving Milling Machines
| CNC engraving and milling machine parameters | ||||||
| Project | Unit | TAT-650 | TAT-660 | TAT-760 | TAT-8080 | TAT-1080 |
| X-axis travel | mm | 500 | 600 | 600 | 800 | 800 |
| Y-axis travel | mm | 600 | 600 | 700 | 800 | 1000 |
| Z-axis travel | mm | 260 | 260 | 350 | 400 | 400 |
| Spindle nose to table | mm | 50-310 | 50-310 | 30-290 | 70-470 | 70-470 |
| Three-axis guide width | X/Y:30 Z:25 | X/Y:30 Z:25 | X/Y/Z:30 | X/Y/Z:MSA35 | X/Y/Z:MSA35 | |
| Table size | mm | 500*600 | 600*600 | 600*700 | 800*800 | 800*1000 |
| T-slot | mm | 6*16*90 | 6*16*90 | 6*16*90 | 7*18*100 | 9*18*100 |
| Max load capability | kg | 300 | 300 | 300 | 400 | 400 |
| Standard spindle | Motorized spindle | Motorized spindle | Motorized spindle | Motorized spindle | Motorized spindle | |
| Spindle speed | rpm | 3000-24000 | 3000-24000 | 3000-24000 | 3000-24000 | 3000-24000 |
| Spindle power | 5.5 | 5.5 | ||||
| Spindle taper | ER25-32 | ER25-32 | ER25-32 | ER25-32 | ER25-32 | |
| Maximum cutting feed rate (X/Y/Z) | m/min | 8 | 8 | 8 | 8 | 8 |
| Rapid speed(X/Y/Z) | m/min | X/Y/Z:15 | X/Y/Z:15 | X/Y/Z:15 | X/Y/:18 Z:15 | X/Y/:18 Z:15 |
| Ball screw diameter/pitch | mm | X/Y/Z:32/5 | X/Y/Z:32/5 | X/Y/Z:32/5 | X/Y:40/6 Z:32/5 | X/Y:40/6 Z:32/5 |
| Positioning accuracy | mm | ±0.005/300 | ±0.005/300 | ±0.005/300 | ±0.005/300 | ±0.005/300 |
| Repeatability | mm | ±0.003 | ±0.003 | ±0.003 | ±0.003 | ±0.003 |
| Air pressure | kgf/cm² | 6 | 6 | 6 | 6 | 6 |
| Net weight of machine | kg | 3200 | 3400 | 3600 | 4800 | 5300 |
| Area | mm² | 1950*1895 | 1950*1895 | 1950*1895 | 2450*2150 | 2750*2150 |
| Machine height | mm | 2355 | 2355 | 2355 | 2673 | 2673 |
TAT-760 4 Axis CNC Engraving Milling Machines
