Photocell Sensor for Automatic Gate Opener with Infrared Beam Detection

Product Description

Infrared Photocell 12V 24V for Auto Gate and Garage Door Openers: An Essential Photocell for Automatic Gate Systems.
Key Features: * Boasting an effective anti-glare feature rated up to an impressive 50,000LUX, this sensor is equipped with an advanced automatic glare filtration system. This ensures optimal performance by reducing the disruptive impact of bright lights or vehicle headlights. * Engineered to withstand diverse weather conditions, including rain, fog, and dust, this sensor is sealed to operate seamlessly even in the most challenging environments, ensuring uninterrupted functionality. * Intelligent sensitivity adjustment thanks to the AGC circuit, which automatically calibrates the detector to maintain accurate performance during foggy or adverse weather. * Unrivaled resistance to both radio frequency interference (RFI) and electromagnetic interference (EMI), guaranteeing stable and reliable operation. * Features an innovative digital filter circuit design that enhances the accuracy and reliability of the sensor's performance. * Utilizes high-power transmitter components achieving a remarkable 90% sensitivity margin. The infrared receiver incorporates low-power processing technology complemented by anti-lightning circuitry for enhanced durability. * Includes a thoughtfully designed rain cover to protect the sensor from the elements. * Equipped with a C-type relay output for versatile integration into various systems. * Offers adjustable beam interruption periods, providing enhanced flexibility and adaptability to suit specific application needs. * Designed with a professional-grade anti-interference optical cover, ensuring clarity and precision in detection. Technical Specifications: * Outdoor Guard Distance: 20m ensures secure perimeter protection. * Indoor Alert Distance: 30m provides extended coverage for indoor spaces. * Sensing Speed: Swift 30ms response time for rapid detection. * Alarm Output - Normal: Offers both Normally Closed (NC) & Normally Open (NO) contact capacity suitable for AV/DC 30V/0.5mA, ensuring reliable alarm activation. * Alarm Linkage: Fully supported for a comprehensive security network. * Working Voltage: Compatible with DC12-24V, ensuring easy integration into existing systems. * Housing Material: High-quality Polycarbonate (PC) for durability and longevity. Whenever the light beam between the emitter and receiver is interrupted, the device promptly issues an alarm signal, enhancing security measures.
Product Description
Product type
infrared sensor, photocell, detector: Specialized in detection for automation and security applications.
Spec.

Power	12/24v AC&DC
Range	≤ 20 meters
Tem.	-10ºC -70ºC
Frequency	1.92 KHZ
wave length	940 nm
input	rx 15 mA Tx 30mA
Relay output	1A maz 36v
Technology	infrared
Dimention	49.2*76*21.6 mm

1, Over 200 model variations; welcomes OEM & ODM projects to meet diverse needs.
2, Compliant with CE, RoHS, and ISO standards, ensuring safety and quality.
3, Unique patent molds for enclosures, offering distinctive and protected design solutions.
4, Serving markets across Europe, South and North America, Asia, and beyond, ensuring global reach and reliability.
5, Sample offerings available for thorough testing and evaluation.
Trade terms
1). Payment: T/T only, with 30% deposits required before production, and the remaining 70% balance due before delivery.
2). Sample delivery within 3-5 days for quick assessment.
3). Shipping freight quoted per your requests, ensuring cost-effectiveness and convenience.
4). Attractive discounts available based on order quantities, offering better value for bulk purchases.
5). Competitive FOB prices are available upon inquiry to meet your budget requirements.
