Yuchai Ycr280e Rotary Drilling Rig
| US$70,000.00-120,000.00 | 1 units (MOQ) |
Basic Info.
Model NO.
YCR280E
Type
Rotary Drilling Rig
Shotcrete Type
Dry
Machining Process
Hydraulic
Structure
Rotor Type
Productivity
180m²/h
Feeding Height
1400mm
Certification
ISO9001: 2000, CE
Condition
New
Color
Red
Engine Model
X12
Engine Power
280kw
Rated Speed (Rpm)
2100rpm
Maximum Drilling
2000mm
Total Mass of The Entire Machine
70t
Transport Package
16565*3432*3510
Specification
11245*4400*22792
Trademark
YUCHAI
Origin
Changsha
HS Code
8705909000
Production Capacity
100units/Year
Product Description
Product Parameters| YCR280E | ||
| (Main parameter) | (Units) | (Parameters) |
| Chasis | ||
| EngineModel | X12 | |
| RatedPower/RotarySpeed | kW/rpm | 280/2100 |
| Track width(margin) | mm | 4400 |
| Track shoe width | mm | 800 |
| Traction force | kN | 580 |
| Rotary Drive | ||
| Max.output torque | kN.m | 280 |
| Rotaryspeed | rpm | 6~24 |
| Max.pull-down piston push | kN | 220 |
| Max.pull-down piston pull | kN | 250 |
| Max.pull-down piston strlke | mm | 5000 |
| Mainwinch | ||
| Max.pulling force | kN | 260 |
| Max.pullingspeed | m/min | 55 |
| Wire Rope Diameter | mm | 32 |
| Auxiliary winch | ||
| Max.pulling force | kN | 80 |
| Max.pullingspeed | m/min | 25 |
| Wire Rope Diameter | mm | 20 |
| MastRake | ||
| Forwardsbackwards | 5 | |
| Sidebackwards | ±4 | |
| Hydraulic system | ||
| Max.working pressure of main pump | MPa | 34 |
| Drilling hole | ||
| Max.Drilling Diameter | mm | 2000/2500() |
| The max.drilling depth | m | 80(MZ) |
| The max.drilling depth | m | 54(JS) |
| Main machine | ||
| Total working weight | t | 90 |
| Transportation weight(Removetherotating device) | t | 70 |
| Transportationweight(Remove the rotating device,power head,balance weight) | t | 57 |
| Transporting state sizeI | mm | 16565×3432×3510 |
| Transporting state sizeI | mm | 14935×3432×3510 |
| Working statesize | mm | 11245×4400×22792 |
| Recommended drill pipe type | ||
| Friction rod configuration | p508-6×14.5m | |
| Machine lock lever configuration | p508-4×14.5 m | |
Detailed Photos
