Banbury Mixer Kneader Machine Dalian Deyu Dy-160L

Banbury Mixer Kneader Machine Dalian Deyu Dy-160L

US$235,000.00-245,000.00 1 Set (MOQ)

Basic Info.

Model NO.
DY-160L
Certification
ISO
Condition
New
Customized
Customized
Automatic Grade
Automatic
Structure
Vertical
Transport Package
Steel Pallet
Trademark
Deyu Machinery
Origin
Dalian China
HS Code
8477900000
Production Capacity
5000 Sets/Year

Product Description


Deyu patent product new type banbury mixer
Features at:
1) this machine has an integral structure, with a compact structure and good leak proofness, comparing with the traditional drop-type
banbury mixer, it has the features of easy installation, small space occupied, smaller pollution, most suitable for the condition of limited
factory building space, and it can give play to the best efficiency, convenient to provide the possibility of automatic rubber mixing.
it is the ideal new type rubber mixing equipment for the medium size rubber products factory.
2) This machine raises the production efficiency greatly, enhances the rubber mixing quality and reduces the unit energy consumption
effectively, its rubber mixing quality and efficiency is same as the traditional drop-type banbury mixer, but the energy required is 2/3 of
the traditional banbury mixer.
3) All the rotors, mixing chamber, discharge door, the top ram etc. can be cooled through water circulation with large cooling area,
meanwhile this machine is equipped with the water temperature control system ,which can effectively ensure the mixing quality
of various rubber materials.
4) The surface of the rotors adopts hydraulic sealing, the sealing specific pressure is adjustable, reliable sealing.
5)The top ram adopts hydraulic drive, to realize constant pressure control of rubber marterials, the bottom ram adopts drop-type
for discharging with hydraulic drive, stable runnng, short opening and closing time, being driven by oil cylinder, tight locking force
is strong, good self-locking and sealing properly.
6) This machine adopts intelligent control system equipped with inverter, its control system adopts touch screen and PLC, while
the touch screen can transmit and display the running condition of the machine effectively, also it can be set different pressure
and rotating speed according to different kinds of material and then all the settings can be on file by serial number, and the relevant
procedure will be callout by inputting the relevant serial number during late productio procedure to run the machine.
7) This machine can select the best rotating speed and pressure according to the hardness and temperature of materials, combining
the electric current, to get the best rubber mixing effects, with the features of going green and environmental protection and intelligentize.
8) This machine can choose to assemble front and rear auxiliary equipments to work continiously according to user's requirements,
to realize automatic rubber mixing.
Detailed specification:
DY-50L DY-60L DY-80L DY-90E DY-110L DY-160L
total volume of mixing chamber 60L 90 120 90 165 240
working volume of mixing chamber 45L 60 80 60 110 160
driving motor power 90 kw 132 185 400 280 400
hydraulic motor power 5.5 kw 7.5 7.5 11 11 11
front rotational speed of the rotor 40(adjustable) 40 40 40 40 40
speed ratio of rotors 1:1.2 1:1.2 1:1.2 1:1.2 1:1.2 1:1.2
consumption of cooling water 20M3/hour 25 25 35 35 50
Pressure of heating steam(rubber mixing) 0.3-0.4Mpa 0.3-0.4 0.3-0.4 0.3-0.4 0.3-0.4 0.3-0.4
Pressure of heating steam(plastic mixing) 0.5-0.8Mpa 0.5-0.8 0.5-0.8 0.5-0.8 0.5-0.8 0.5-0.8
Dimension (mm) 4500
2450
3890
4600
2500
4090
4700
2670
4240
5470
2760
4720
5340
2790
4580
5900
3300
4900
Weight 10 ton 13.5 16.5 22 22.5 39
Ram form hydraulic ram hydraulic ram hydraulic ram hydraulic ram hydraulic ram hydraulic ram
