HG-KN13J-S100 Mitsubishi 0.1kw Rated Output Power Servo Modular

Product Details

Product Description

Product Description
Detailed Product Description
Category:Model:Rated Output Power:Rated Speed:Series:Brand:High Light:

Industiral Servo Motor	HG-KN13J-S100
100w	3000r/min
HF-KN	Mitsubishi
ewing machine servo motor,electric servo motor

MITSUBISHI 100W Industrial AC SERVO MOTOR HG-KN13J-S100 Rated speed 3000r/min
Specifications

FUNCTIONS	PARAMETERS
Brand Name	Mitsubishi
Model Number	HG-KN13J-S100
Rated output (kW)	0.1
Rated torque (N.m)	0.32
Maximum torque (N.m)	0.95
Rated speed (r/min)	3000
Maximum speed (r/min)	5000
Rated current (A)	0.8
Maximum current [A]	2.4
Speed/position detector	17-bit encoder common to absolute position/incremental
Mass (kg)	0.74

Related Products:
Product Name: Rotary servo motor.
Model: HG-KN13J-S100.
Inertia/capacity: Low Mitsubishi HG-KN43J-S100 inertia, small capacity.
Rated output: 0.1 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic Mitsubishi HG-KN43J-S100 brake: None.
Product Name: Rotary servo motor.
Model: HG-KN23J-S100.
Inertia/capacity: Low Mitsubishi HG-KN43J-S100 inertia, small capacity.
Rated output: 0.2 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic brake: None.
Product Name: Rotary servo motor.
Model: HG-KN23BJ-S100
Inertia/capacity: Low inertia, small capacity.
Rated output: 0.2 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic brake: Installed.
Product Name: Rotary servo motor.
Model: HG-KN43J-S100
Inertia/capacity: Low inertia, small capacity.
Rated output: 0.4 kW.
Rated speed: 3000 r/min.
Oil seal: Installed.
Electromagnetic brake: None
Product Name: Rotary servo motor.
Model: HG-KN73J-S100.
Inertia/capacity: Low inertia, small capacity.
Rated output: 0.75 kW.
Rated speed: 3000 r/min.
Oil HG-KN43J-S100 seal: Installed.
Electromagnetic brake: None.
Corresponding servo amplifier: MR-JE-10B/MR-JE-10A.
Support position control, speed control, torque control, push and press control.
Position control can use linear, arc interpolation controller, fixed size feed control, target position change and other rich functions.
The position control and torque control are realized by switching control mode.
The gain adjustment of servo can be simply performed by the advanced one key tuning function.
At the same time, it is also able to suppress the low frequency vibration of the manipulator by the advanced vibration suppression control II,
Shorten the time to complete the positioning, so as to achieve the production of the rhythm of the shortening.
