700bph Plastic Bottlle Blowing Making Machine

700bph Plastic Bottlle Blowing Making Machine

US$9,000.00-55,000.00 1 Set (MOQ)

Basic Info.

Model NO.
Lk-1500s
Making Method of Parison
Stretch Blow
Automation
Non-Automatic
Computerized
Computerized
Certification
CE, ISO9001:2008, QS, GMP
Model
Lk-1500s
Control System
Computerized
Bottler Material
Pet
Bottle Volume
100ml to 2500ml
Machine Installation Power
30kw
Suitable for
Water Bottle, Beverage Bottle, Oil Bottle...Ect
Workers Requests
2 Workers
Certificate
SGS, ISO, Ce,..
Weight
1200kgs
Transport Package
Wooden Export Package
Specification
ISO, SGS, CE
Trademark
LINKS
Origin
Zhangjiagang City, China
HS Code
84774010
Production Capacity
50/Month

Product Description

*Introduction
Links Stretch Blow Molding Machine is suitable to produce different shapes of PET/PC/PE bottles. It can blow from 100ml to 6000ml bottles and is widely used to produce mineral water bottles,carbonater soft drink bottles,juice bottles,medical botties,cosmetic and oil bottles etc.
1,Infrared lamps adoped in the pre-heater ensures PET preforms being heated evenly.
2,Mechanical-double-arm calmping ensures mould being tightly closed under hight pressure and high temperature.
3,Pneumatic system consists of two parts. pneumatic acting part and bottle blowing part in order to meet different requirements for both acting and blowing. It provides sufficient steady high pressure to blowing. It provides sufficient steady high pressure to bloww large irregular shape bottles.
4,Equipped with silencer and oiling system to lubricate the mechanical pars of the machine.
5,Operated step-by-step and in semi-auto maode.
6,Wide-mouth jar and hot-fill bottles can also be made.
*Parameter
Model LKS-900BHR LKS-1500BHR LKS-400BHR LKS-700BHR LKS-100BHR
Product material PET PET PET PP PET
Bottle Volume 50-2000ML 50-2000ML 5-10L 50-2000ML 10-20L
Max.bottle height 360MM 360MM 400MM 250MM 550MM
Max.bottle diameter 120MM 120MM 220MM 80MM 280MM
Main machine
(L×W×H)
1600×600×1600
MM
1600×650×1600
MM
1750×750×1700
MM
1600×650×1600
MM
2300×850×2150
MM
Main machine weight 500KG 560KG 800KG 560KG 670KG
Heater
(L×W×H)
1760×630×1380
MM
1870×650×1450
MM
1870×630×1450
MM
4600×650×1400
MM
2800×770×1750
MM
Heater weight 260KG 270KG 270KG 600KG 270KG
Output 900PCS/HR 1500PCS/HR 400PCS/HR 700PCS/HR 100PCS/HR
The actual output depending on the bottle size,shape and weight

*About Links Machinery

FAQ: Q: Can your company provide turnkey project from A to Z?
A: Yes, we can provide the turnkey project for beverage production line, from PET preform and cap making machine, PET bottle blowing machine, water treatment plant, juice or carbonated drink mixing plant, filling and packing machines.
Q: How can I know the quality of your machines before I order?
A: We have many projects in different countries, with the customers' permission, we can guide you to visit the factories and see the machines running. You are also very welcome to visit our company in China to see the machine running in our factory.
Q: How can we check our machines if we order the machines from you?
A: We will test all the machines before shipment, you can come to inspect the machines or we can take videos for you.
Q: What is the guarantee or warranty of your machines?
A: We give 18 months warranty for the mechanical parts and 12 months warranty for the electric parts.
Q: For a new starter, how can you help me start and run a water or beverage bottling plant?
A: We can help you do the bottle design, label design and choose the suitable labeling and package type according to your local market. If you have confirm the factory size, we can also make the machine layout design accordingly. We can help you install the machines, train your staff how to operate, maintain the machines and even help you hire experienced Chinese engineer to work in your factory as a production manager.
