Hot Press Wood Pallet Foot Pier Machine

Product Description

We mainly develop and manufacture: foot pier nailing machine, pallet foot pier machine, straw foot pier machine, wood chip pad hot press, wood pallet slotting machine, wood pallet chamfering machine, 45 degree angle machine, wood square pier multi-piece saw, multi-layer board foot pier machine, CNC electronic cutting saw, wood pallet double-head saw, automatic cutting pier machine, shaving pier machinery, wood pallet automatic nailing machine production line, shaving wood chip drying and other industry-specific equipment.
Wood block hot press, wood pallet foot pier hot press, wood pallet foot pier press, wood pallet foot pier press, wood block press, wood pallet foot pier forming machine, wood pallet foot pier manufacturing machine, etc.
1, Product Features: Our wooden block hot press for wooden pallet feet has the following characteristics:
Simple operation: One person can operate the machine automatically to complete the steps of feeding, pressing, left and right nailing, and cutting to a fixed length. High yield and fast speed: The hourly output is about 1200, and the output is doubled. Utilize waste wood, wood shavings, and wood as raw materials, dried by a drying machine, mixed uniformly with glue, and hot-pressed into a shape with no debris, good waterproof performance, and strong nailing force. According to its production type, it is divided into three types: single-head, double-head, and three-head. The molds used are made of stainless steel, which can further extend the service life of the molds. High efficiency: The wooden block hot press adopts advanced heating and pressure control systems, which can quickly heat the wood to the appropriate temperature and apply high pressure, shortening the hot pressing time and improving production efficiency. Energy-saving and environmental protection: The wooden block hot press adopts efficient heating methods that can reduce energy consumption. At the same time, it adopts a closed hot pressing chamber that can reduce heat loss and exhaust emissions, in line with environmental protection requirements. High safety: The wooden block hot press is equipped with multiple safety protection devices that can ensure safe operation and stable equipment operation. Strong customizability: Different specifications, models, and functions can be customized according to different customer needs and requirements. Easy maintenance: The wooden block hot press adopts a modular design that is easy to disassemble and maintain. At the same time, the equipment runs stably and reliably, reducing maintenance frequency and costs. In summary, the wooden block hot press is an efficient, energy-saving, environmentally friendly, safe, customizable, and easy-to-maintain wood processing equipment widely used in furniture, flooring, doors and windows and other interior decoration industries.
2, Specification:
The wood pallet foot making machine can make different size wood block as per your request.
The sizes are 75*75,80*100,80*120,90*90,90*140,100*100,100*115,100*140,140*140 etc.

Model	Double Head(one head in each side)	Four Head(two heads in each side)	Six head(three heads in each side)
Size(mm)	4800*500*1420mm	4800*580*1420mm	4900*940*1420mm
Capacity	2-3m3/24h	4-6m3/24h	6-8m3/24h
Glue water amount	100-120kg/m3	100-120kg/m3	100-120kg/m3
Density	550-600kg/m3	550-600kg/m3	550-600kg/m3
Weight	1000kg	1500kg	2200Kg
Power	12kw	16-18kw	24kw

Wood Pallet Block Machine With Automatic Pallet Block Saw (Manual cutting saw can be selected)
2, Details:
The working process of pallet block machine can be summarized as follows:
Feeding: The wood strip is conveyed into the heating plate. Pressing: The high-pressure hydraulic cylinder pushes the piston to extrude and press the material, so that the urea-formaldehyde glue can be heated and solidified rapidly. Heating: The heating plate is heated to a high temperature to promote the solidification and molding of the urea-formaldehyde glue. Cutting: According to a certain length (usually around 1.2 m), the wood strip is cut into a long wooden strip. Cooling: The long wooden strip is cooled down after molding. Cutting: The long wooden strip is cut into the final size after cooling. Packing: The finished products are packed and stacked in a row for use. The pallet block machine is used to make the wooden pallet base, which is used for transportation or storage pallets. The final product can achieve E1 grade, and the pallet block can be solid without a hole in the center, or hollow.
4, Whole Production Line
1.Wood crusher machine: It is used for the raw materials in larger size. Please use wood shavings and sawdust to make wood blocks. If the raw material is not very big, it is unnecessary to crush. 2.Dryer machine Drying the raw material to keep the 10%-15% moisture.
3.Gluing machine Mixing the material together tighter for next step.
4.Wood pallet block making machine (main machine of the wood block production line)
4.Cooling and cutting: After hot pressing, the foot pier needs to be cooled and cut to the required size.
