Outdoor Indoor Events Movable Stages LED Video Wall Screen Panel P3.91 Advertising Display
| US$100.00-399.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
SY-P3.91-16S-E
Pixel Pitch
3.91mm
Pixel Configuration
1R, 1G, 1B
Display Function
Video Display, Image & Text Display
Average Power Consumption
350W / m²
Pixel Density
65410 Dots/M2
Scanning Mode
1/16 Scan
Display Type
LED Video Display
Application
Stage Performance
Certification
CE, RoHS, CCC, ETL, FCC, ISO9001
Control Mode
Synchronous Display with Control PC by DVI
Control System
Novastar, or Linsn, or Colorlight, or as Required.
Display Content
Video, Picture, Cartoon, Graphics, Texts.etc.
Interface
Standard Ethernet
with Video Processor
Video, VGA, HDMI, DVI, SDI/HD-SDI/3G-SDI
Cabinet Material
Die Casting Aluminum
Cabinet Size
500mm X 1000mm
Cabinet Weight
13.5kg Per Cabinet
OEM
Yes
Transport Package
Wooden Box or Flight Case
Specification
P3.91
Trademark
SENY
Origin
Shenzhen, China.
HS Code
8528591090
Production Capacity
100000
Packaging & Delivery
Package Size
108.00cm * 71.00cm * 74.00cm
Package Gross Weight
123.000kg
Product Description
Outdoor Indoor Events Movable Stages LED Video Wall Screen Panel P3.91 Advertising DisplayProduct features:
1. Ideal for indoor & outdoor rental events stage performance ;
2. Very high cost effective;
3. High refresh rate more than 3840Hz;
4. Light weight design cabinet for options;
5. Excellent image quality, running stable;
6. High resolution;
7. Simple installation to make it more and more popular.
Technical Parameter:
| Item Name | Technical Parameter | ||
| LED Parameter | |||
| Item Name | LED Type | ||
| Red LED | SMD1921 | ||
| Green LED | SMD1921 | ||
| Blue LED | SMD1921 | ||
| Module Parameter | |||
| Pixel Pitch | 3.91mm | ||
| Pixel Configuration | 1R1G1B | ||
| Module Resolution | 64 x 64 pixels | ||
| Module Pixles | 4096 pixels | ||
| Module Size | 250mm x 250mm | ||
| Cabinet Parameter | |||
| Cabinet Size(W X H X D) | 500mm x 1000mm x 80mm | ||
| Cabinet Resolution(dot) | 128 x 256 pixels | ||
| Module Quanity (pcs) | 8pcs | ||
| Cabinet Pixels | 32768 pixels | ||
| Pixel Density | 65536 pixels/m2 | ||
| Cabinet Type | Die Casting Aluminum | ||
| Cabinet Weight | 13.5kg per cabinet | ||
| Whole Screen Parameter | |||
| Screen Brightness | 4500cd/m2 | ||
| Driving Method | 1/16 scan, constant current driving | ||
| Min. Viewing Distance | 3m | ||
| Max. Power Consumption | ≤ 800W/m2 | ||
| Ave. Power Consumption | ≤ 400W/m2 | ||
| Gray Levels | 14 bits | ||
| Frame Frequency | ≥60Hz | ||
| Refresh Frequency | 3840Hz | ||
| LED Life-span | ≥100,000 hours | ||
| MTBF | ≥5,000 hours | ||
| Discrete Blind Spot Rate | <1/10000 | ||
| Continuous Blind Spot Rate | None | ||
| Blind Spot Rate | <1/10000 | ||
| Protective Scale | IP65 | ||
| Screen Plainness | <±1mm | ||
| Power Supply Mode | AC220±10% 50Hz/AC110±10% 60Hz | ||
| Working Temperature | Temperature: 0 Celsius~+40 Celsius | ||
| Storage Temperature | Temperature:-30 Celsius~+50 Celsius | ||
| Humidity | Humidity:10%~90% RH | ||
| Control Mode | Synchronous display with control PC by DVI | ||
| Control System | Novastar, Linsn, Colorlight or as you required. | ||
| Display Content | Video, picture, cartoon, graphics, texts.etc. | ||
| Interface | Standard Ethernet | ||
| Transmission Distance | Multi mode fiber <500m, single mode fiber <20km,internet cable <100m | ||
| With Video Processor(optional) | Video,VGA,HDMI,DVI,SDI/HD-SDI/3G-SDI | ||
Applications:
Production Process:
Certification:
Packaging and Shipping:
Our service
Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offered.
5. Other required services such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
3. Free spare parts provided.
After-sale service:
1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 1year
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
