Portable 52m Concrete Pump Hb52 Good Price Concrete Pump Parts
| US$143,000.00-265,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HB52
Type
Concrete Pump
Shotcrete Type
Semi-Dry
Machining Process
Hydraulic
Structure
Spiral Type
Productivity
120m²/h
Feeding Height
1380mm
Vibrating Amplitude
2.2mm
Certification
ISO9001: 2000, CE
Condition
New
Color
Red
Wheelbase
1995mm
Output Power
324kw
Displacement
12.8L
Slewing Radius
47.5m
Transport Package
Nude
Specification
10650*2500*3700mm
Trademark
NEWINDU
Origin
China
HS Code
87059090
Production Capacity
100
Product Description
portable 52m concrete pump HB52 good price concrete pump parts
Product description
HB52 concrete pump is the medium size of machine, and widely applied in high buildings and large foundation equipments of bridge, power plant, steel plant, water treatment plant. The machine features environmental care, safety, reliability and advanced.
| Category | Item | Unit | Parameter |
| Chassis | Model | FM440 | |
| Max. speed | km/h | 90 | |
| Max. gradeability | 38% | ||
| Min. turning diameter | m | 27.4 | |
| Brake distance | m | ≤10 | |
| Wheelbase | mm | 1995+5205+1370+1450 | |
| Tread (front/rear) | mm | 2028/1872 | |
| Approach angle/departure angle | . | 18/12 | |
| Min. clearance | mm | 270 | |
| Tyre specification | 12.00R20 | ||
| Engine | Model | D13 | |
| Output power | kw/(r/min) | 324/1400~1800 | |
| Max. torque | N.m/(r/min) | 2200/1050~1400 | |
| Displacement | l | 12.8 | |
| Emission Standard | Nation III GB | ||
| Others | Dimension (Length×Width×Height) | mm | 14665×2500×3990 |
| Total vehicle weight | kg | 47000 | |
| Fuel tank capacity | l | 410 | |
| Fuel consumption per 100km | l/100km | 50 | |
| Pumping system | Theoretical output(high pressure/low pressure) | m³/h | 90/138 |
| Concrete pumping pressure(high pressure/low pressure) | Mpa | 13/8.7 | |
| Theoretical pumping times(high pressure/low pressure) | Times/min | 18/27 | |
| Max. diameter of pumping concrete aggregate | 40 | ||
| Feeding height | 1450 | ||
| Placing boom | Pumping slump range | 12-23 | |
| Reach height | 51.5 | ||
| Reach depth | 40 | ||
| Slewing radius | 47.5 | ||
| Slewing angle | 364 | ||
| 1st boom stretch angle | 96 | ||
| 2nd boom stretch angle | 180 | ||
| 3rd boom stretch angle | 180 | ||
| 4th boom stretch angle | 180 | ||
| 5th boom stretch angle | 260 | ||
| Outrigger spanOverall outrigger span | 11020±50 | ||
| Front outrigger transverse span | 10730±50 | ||
| Rear outrigger transverse span | 10430±50 | ||
| Others | Dosing type | S valve | |
| Lubricating method | Automatic lubrication | ||
| Controlling method | Manual/remote control | ||
| Water tank capacity | 650 | ||
| Max. pressure of water pump | 2 |
Product image:
