Material Laser Collimating Lens 0.6 Numerical Aperture 4.05mm Focal Length L-Bal42 Wavelength 639um
| US$1.50-5.50 | 100 Pieces (MOQ) |
Basic Info.
Model NO.
M14P0508F1015-47
Type
Collimating Lens
Transmittance
>95%
Shape
Ball, Hemisphere
Material
Optical Glass
Lenses Color
Clear
Customized
Customized
Coating
HC
Wavelength
400um-700um
Transport Package
Carton
Specification
M6, M7, M8, M9, M10
Trademark
3V-Tech
Origin
China
HS Code
3225961661
Product Description
Product Description A collimating lens is an instrument that converts light from each point in the aperture column into a parallel column of collimating light.Lens type depends on aberration requirements,For low requirements, simple lenses, such as flat convex or double convex lenses, maybe used and a larger relative aperture is allowed.High requirements,Achromatic lens will be use, the relative aperture is also appropriately reduced.Collimator lens is one of the mainly products in Sunday. We have standard ones and also accept customer-made. 3V-tech has collimator lens with single aspheric, doublet lenses, triplet lens.Specification:
Shell Material: Aluminum or Copper.
Lenses:aspheric lens,two lenses,three lenses (Glass),single apron, two aprons.
We also accept customization.
Product Parameters
No. | Size (mm) | EFL (mm) | NA | CA (mm) | Aperture working distance (mm) | Design wavelength λ(nm) | Material | Coating (nm) |
| M7P0505F0302-47 | M7×P0.5×5.0 | 2 | 0.54 | 2.4 | 0.7 | 650 | D-ZK3 | 400-700 |
| M9P0505F0302-47 | M9×P0.5×5.0 | 2 | 0.54 | 2.2 | 0.7 | 650 | D-ZK3 | 400-700 |
| M9P0508F0302-47 | M9×P0.5×8.0 | 2 | 0.54 | 2.4 | 0.7 | 650 | D-ZK3 | 400-700 |
| M9P0508F0302-S-47 | M9×P0.5×8.0 | 2 | 0.54 | 2.4 | 0.7 | 650 | D-ZK3 | 400-700 |
| 9P0508F0302-S-47 | M9×P0.5×8.0 | 2 | 0.54 | 2.4 | 1 | 650 | D-ZK3 | 400-700 |
| M9P0510F0302-S-47 | M9×P0.5×10.0 | 2 | 0.54 | 2.4 | 0.7 | 650 | D-ZK3 | 400-700 |
| M9P0565F0302-47 | M9×P0.5×6.5 | 2 | 0.54 | 2.4 | 0.7 | 650 | D-ZK3 | 400-700 |
| M6P0505F0306-47 | M6×P0.5×5.0 | 6 | 0.2 | 2.4 | 4.71 | 530 | D-ZK3 | 400-700 |
| SJLTF061000-6580 | M9×P0.5×7.5 | 10 | 0.25 | 5 | 3.88 | 635 | D-ZK3 | 650-800 |
| M9P0506F0612-D-47 | M9×P0.5×6.0 | 12 | 0.23 | 5.5 | 10.14 | 530 | D-ZK3 | 400-700 |
| M9P0508F0612-47 | M9×P0.5×8.0 | 12 | 0.23 | 5.5 | 8.64 | 530 | D-ZK3 | 400-700 |
| M9P0508F0612-D-47 | M9×P0.5×8.0 | 12 | 0.23 | 5.5 | 10.14 | 530 | D-ZK3 | 400-700 |
| M9P0510F0612-D-47 | M9×P0.5×10.0 | 12 | 0.23 | 5.5 | 4.6 | 530 | D-ZK3 | 400-700 |
| M9P0508F0615-47 | M9×P0.5×8.0 | 15 | 0.15 | 5 | 8.88 | 635 | D-ZK3 | 400-700 |
| M9P0508F0708-47 | M9×P0.5×8.0 | 8 | 0.33 | 5.4 | 6.13 | 635 | D-ZK2 | 400-700 |
| M9P0510F0708-47 | M9×P0.5×10.0 | 8 | 0.33 | 5.4 | 6.13 | 635 | D-ZK2 | 400-700 |
| M9P0510F0708A2-47 | M9×P0.5×10.0 | 8 | 0.33 | 5.4 | 2.62 | 635 | D-ZK2 | 400-700 |
| M9P0510F0708B1-47 | M9×P0.5×10.0 | 8 | 0.4 | 6.5 | 6.13 | 635 | D-ZK2 | 400-700 |
| M9P0575F0708-47 | M9×P0.5×7.5 | 8 | 0.38 | 6 | 2.92 | 635 | D-ZK2 | 400-700 |
| M9P051519F0708-47 | M9×P0.5×19.0 | 8 | 0.28 | 5.1 | 2.66 | 635 | D-ZK2 | 400-700 |
| M9P051519F0708-D-47 | M9×P0.5×19.0 | 8 | 0.28 | 5.1 | 2.66 | 635 | D-ZK2 | 400-700 |
| M12P051421F0708-7011 | M12×P0.5×21.0 | 8.1 | 0.4 | 6.4 | 3.278 | 905 | D-ZK2 | 700-1100 |
| M10P0508F0811-47 | M10×P0.5×8.0 | 11.2 | 0.31 | 7 | 8.875 | 635 | D-ZK3 | 400-700 |
| M14P0508F1015-47 | M10×P0.5×8.0 | 15.18 | 0.3 | 9.5 | 10.35 | 639 | L-BAL42 | 400-700 |
| M6P0505F3038-47 | M6×P0.5×5.0 | 3.77 | 0.3 | 2.4 | 2.51 | 635 | L-BAL35 | 400-700 |
| M6P0506F3038-47 | M6×P0.5×6.0 | 3.77 | 0.3 | 2.4 | 2.51 | 635 | L-BAL35 | 400-700 |
| M7P0565F4762-47 | M7×P0.5×6.5 | 6.2 | 0.3 | 4 | 3.59 | 633 | D-ZK3 | 400-700 |
| M8P0508F4762-47 | M8×P0.5×8.0 | 6.2 | 0.3 | 4 | 3.59 | 633 | D-ZK3 | 400-700 |
| M9P0508F4762-47 | M9×P0.5×8.0 | 6.2 | 0.3 | 4 | 3.59 | 633 | D-ZK3 | 400-700 |
| M9P0508F4762-S-47 | M9×P0.5×8.0 | 6.2 | 0.3 | 4 | 3.59 | 633 | D-ZK3 | 400-700 |
| M9P0508F4780-47 | M9×P0.5×8.0 | 8 | 0.25 | 4 | 5.44 | 530 | D-ZK3 | 400-700 |
| M9P0508F4780-D-47 | M9×P0.5×8.0 | 8 | 0.25 | 4 | 2.878 | 530 | D-ZK3 | 400-700 |
| M9P0508F6340-47 | M9×P0.5×8.0 | 4.05 | 0.6 | 5.3 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P0508F6340-7011 | M9×P0.5×8.0 | 4.05 | 0.6 | 5.3 | 2.23 | 445 | D-ZK3 | 700-1100 |
| M9P0508F6340-S-47 | M9×P0.5×8.0 | 4.05 | 0.6 | 5 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P0510F6340-47 | M9×P0.5×10.0 | 4.05 | 0.6 | 5.3 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P0510F6340-7011 | M9×P0.5×10.0 | 4.05 | 0.6 | 5.3 | 2.23 | 445 | D-ZK3 | 700-1100 |
| M9P0510F6340-S-47 | M9×P0.5×10.0 | 4.05 | 0.6 | 5 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P0514F6340-BD-47 | M9×P0.5×14.0 | 4.05 | 0.6 | 5 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P05605F6340-47 | M9×P0.5×6.5 | 4.05 | 0.6 | 5.3 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P051520F6340-D-47 | M9×P0.5×20.0 | 4.05 | 0.6 | 5 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P05605F6340-47 | M9×P0.5×6.5 | 4.05 | 0.6 | 5.3 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P051520F6340-D-47 | M9×P0.5×20.0 | 4.05 | 0.6 | 5 | 2.23 | 445 | D-ZK3 | 400-700 |
| M9P0508F6380-S-47 | M9×P0.5×8.0 | 8 | 0.33 | 5.5 | 6.49 | 530 | D-ZK3 | 400-700 |
| M9P051514F6380-D-47 | M9×P0.5×14.0 | 8 | 0.33 | 5.4 | 3.6 | 530 | D-ZK3 | 400-700 |
| M9P0508F635107 | M9×P0.5×8.0 | 10 | 0.17 | 5.2 | 4.71 | 786.5 | L-BAL42 | 786.5±20 |
| M9P0514J048 | M9×P0.5×14.0 | 4.795 | 0.4 | 3.8 | 1.711 | 450 | / | 400-700 |
| M9P051416F273-D-47 | M9×P0.5×16.0 | 13.396 | 0.2 | 5.3 | 2.483 | 650 | / | 400-700 |
| M9P0510F273 | M9×P0.5×10.0 | 12.842 | 0.19 | 5.0 | 7.076 | 405 | / | 400-700 |
| M9P0510F273 | M9×P0.5×10.0 | 13.396 | 0.19 | 5.0 | 7.512 | 650 | / | 400-700 |
| M9P0510F273 | M9×P0.5×10.0 | 13.554 | 0.19 | 5.0 | 7.643 | 850 | / | 700-1100 |
| M9P0510J543 | M9×P0.5×10.0 | 5.378 | 0.3 | 3.4 | 2.95 | 405 | / | 400-700 |
| M9P0510J543 | M9×P0.5×10.0 | 5.434 | 0.3 | 3.4 | 2.916 | 650 | / | 400-700 |
| M9P0510J543 | M9×P0.5×10.0 | 5.46 | 0.3 | 3.4 | 2.923 | 850 | / | 700-1100 |
| M9P051043 | M9×P0.5×10.0 | 9.322 | 0.25 | 5.0 | 3.815 | 405 | / | 400-700 |
| M9P051043 | M9×P0.5×10.0 | 9.635 | 0.25 | 5.0 | 4.018 | 650 | / | 400-700 |
| M9P051043 | M9×P0.5×10.0 | 9.73 | 0.25 | 5.0 | 4.087 | 850 | / | 700-1100 |
| M9P05105-S | M9×P0.5×10.5 | 9.322 | 0.25 | 5.0 | 4.778 | 405 | / | 400-700 |
| M9P05105-S | M9×P0.5×10.5 | 9.635 | 0.25 | 5.0 | 4.981 | 650 | / | 400-700 |
| M9P05105-S | M9×P0.5×10.5 | 9.73 | 0.25 | 5.0 | 5.050 | 850 | / | 700-1100 |
| M9P0508 | M9×P0.5×8.0 | 9.001 | 0.27 | 5.0 | 3.535 | 405 | / | 400-700 |
| M9P0508 | M9×P0.5×8.0 | 9.795 | 0.27 | 5.0 | 4.260 | 650 | / | 400-700 |
| M9P0508 | M9×P0.5×8.0 | 9.991 | 0.27 | 5.0 | 4.441 | 850 | / | 700-1100 |
| M9P0514J98-BD | M9×P0.5×14.0 | 9.001 | 0.27 | 5.0 | 5.751 | 405 | / | 400-700 |
| M9P0514J98-BD | M9×P0.5×14.0 | 9.795 | 0.27 | 5.0 | 6.476 | 650 | / | 400-700 |
| M9P0514J98-BD | M9×P0.5×14.0 | 9.991 | 0.27 | 5.0 | 6.657 | 850 | / | 700-1100 |
| M9P051614J98-D | M9×P0.5×14.0 | 9.001 | 0.27 | 5.0 | 4.251 | 405 | / | 400-700 |
| M9P051614J98-D | M9×P0.5×14.0 | 9.795 | 0.27 | 5.0 | 4.976 | 650 | / | 400-700 |
| M9P051614J98-D | M9×P0.5×14.0 | 9.991 | 0.27 | 5.0 | 6.657 | 850 | / | 700-1100 |
