Dairy Farm Equipment Hot-DIP Galvanized Beef Cattle Headlock

Product Description

Product Introduction
Robot welding to ensure precise structural dimensions that meet drawing requirements and ensure flexibility in use.
Different type for your option:1000mm, 750mm , 667mm, 600mm, 500mm, 420mm,slopped.
The vertical and curved rod are fully welded at the junction of the upper and lower crossbeams to ensure structural stability.
The automatic return time of the movable rod is ≤ 1.5 seconds.
For beef cattle headlock, we can specially produce with thick support frame.
Anti noise available.
Specification
Main components and materials:in Q235
After welding, all will be overall galvanized .
6m/piece/ 9 cow position, every 3m fastened by special clamps with reinforced column,
Total length can be changed according your requirement(about 3meters or 6 meters).
Types

Type	Distance	cow Age	cow head each pc ( 6meters long )	Unit Price (USD)
JJ-420	420mm	3-6 months	14	23
JJ-500	500mm	6-9 months	12	26
JJ-600	600mm	9-13 months	10	30
JG-667	667mm	13-20 months	9	31
JJ-750	750mm	mature cows	8	32
JJ-1000	1000mm	dry cows	6	34
Slopped type	250mm	younger	20/22	18

All spare part for the installation were included, we can guide the installation and provide drawing.
