Advanced Vertical Turret Milling Machine, CNC Machine Tools for Precision Cutting

Product Description

Product Description
Introducing the VMC-M5, a revolutionary vertical turret machining center that exemplifies exceptional stability and rigidity, setting new standards in machining technology. Crafted with precision, its castings are made from high-quality cast iron that boasts excellent sensitivity and remarkable stability, ensuring no deformation issues. The spindle, a masterpiece of engineering, is crafted from chromium combined with top-tier steel, offering unparalleled cutting ability and precision. The innovative inverted hanging design of the vertical milling head ensures outstanding processing precision, making it incredibly easy to operate and control with effortless braking.
The milling head is enhanced with premium parts imported from Taiwan and meticulously assembled in China, creating a compact structure with unmatched flexibility. It has the ability to swivel around 90°, with a 45° rotation before and after, offering versatile operational capabilities. Equipped with a manual oil pump, it ensures centralized lubrication for the work table and lifting table. Perfectly suited for a variety of industrial applications, it excels in machining hardware parts, machinery components, molds, and automation manipulators.
Main Features
Exceptional Stability Superior Rigidity Unrivaled Flexibility Milling head rotation: 90°, with 45° pre-and post-rotation Equipped with a manual oil pump for centralized lubrication Detailed Photos
Product Parameters

Parameters	Projects	Unit	M3	M4S	M4H	M5
	Table area	mm	254x1270 (10'' x 50'')	254 x1270 (10'' x 50'')	254x 1270 (10'' x 50'')	305x1370 (12'' x 54'')
Table Travel	X Axis	mm	800	800	800	900
	Y Axis	mm	400	400	400	400
	Z Axis	mm	480-500	480-500	480	470
Spindle	Spindle Taper	mm	R8/NT30	R8/NT30	R8/NT30	NT40
	Spindle Stroke	mm	127	127	127	127
	Spindle Speed	Steps	16 (Steps) / Variable
	Spindle Feed	mm	0.076 / 0.003'' 0.038 / 0.0015'' 0.203 / 0.008''
	Spindle Low Speed	r/min	66,110,175,270,550,930,1460,2270,variable
	Spindle High Speed	r/min	132,220,350,540,1100,1860,2920,4540/60,4200
T-slot	Slot x Width	mm	3x16	3 x16	3x16	3 x16
	T-slot spacing	mm	65	65	65	65
Motor	Voltage	v	220/380/415	220/380/415	220/380/415	220/380/415
	Maximum Workpiece Weight	kg	300	300	400	350
	Saddle Width/Length	mm	280 x 150	280 x150	280 x150	350x650
	Ram Stroke	mm	510	510	510	650
	Spindle Diameter	-	85.7	85.7	85.7	105
Distance from Spindle center to Machine Body	Max	mm	120	120	120	120
	Min	mm	700	700	680	810
Distance fron Spindle end to Table	Min	mm	55	100	100	100
	Max	mm	430	460	480	580
Dimension	-	mm	1680x1680x2090	1680x1680x2090	2000x1680x2150	1770x1780x2300
Net Weight		kg	1100	1300	1380	1500

Company Profile
Lizhun Machinery Co., Ltd. is at the forefront of innovation, development, and production of cutting-edge CNC machining centers and CNC lathes. Embodying the spirit of innovation and excellence, Lizhun has consistently delivered high-performance, precision-engineered, and superior-quality machines to renowned enterprises worldwide. Looking forward, Lizhun is committed to upholding its spirit of innovation and excellence, providing robust support to the processing industry and delivering exceptional machining solutions to sectors like 5G, aviation, and the automobile industry.
Positioned in Dongguan, Guangdong Province, Lizhun Machinery Co., Ltd. boasts a product exhibition hall in the serene setting of Songshan Lake, Dongguan City. With a picturesque environment, the facility in Dalingshan is equipped with comprehensive facilities and a team of seasoned professionals dedicated to innovation, development, assembly, and production. This expertise guarantees each machine delivers outstanding quality and performance as they leave the factory. ensuring it leaves the factory with unparalleled excellence.
Spanning a vast area, the facility hosts numerous production lines that bolster its production and supply capabilities. This exceptional capacity ensures machines are delivered to customers within agreed timelines, effectively mitigating issues arising from insufficient capacity.

FAQ
1. Is it all right to make customer's own brand name?
A: yes. we are available with OEM

2. Are you a manufactuer or trading company?
A:We are the manufacturer

3. Can you do the design for us?
A: yes. if you want a different control system design or higher column , we are available.

4 . What is your terms of delivery?
A: FOB shenzhen.

5. What's your payment term?
A: T/T OR L/C at sight.
