Renovl SAE J30r7 High Tensile Polyester Single Fiber Reinforced Fuel Injection Line Emission Control Automotive Hydraulic Flexible High Pressure NBR Rubber Hose

Product Description

RENOVL SAE J30R7 High Tensile Polyester Single Fiber Reinforced Fuel Injection Line Emission Control Automotive Hydraulic Flexible High Pressure NBR Rubber Hose
Product Description
Fuel Ethanol Gaso-line Hose
Fuel ethanol gaso-line hoses are essential components in fuel systems, facilitating the safe and efficient transfer of ethanol-blended gaso-line in a wide range of applications. These hoses play a crucial role in ensuring a reliable fuel supply to vehicles, machinery, and equipment that rely on ethanol-blended gaso-line as a primary fuel source.
Fuel ethanol gaso-line hoses are designed to withstand the unique challenges posed by ethanol-blended gaso-line, which can be more corrosive and have different chemical properties compared to traditional gaso-line. The materials used in these hoses are carefully selected to resist the deteriorating effects of ethanol, preventing degradation and ensuring long-lasting performance.
In addition to material compatibility, fuel ethanol gaso-line hoses are engineered with reinforced layers to withstand high pressures and prevent kinking or collapsing during fuel transfer operations. They are also designed to be flexible and easy to handle, making fueling processes efficient and convenient for operators.Fuel ethanol gaso-line hoses are critical components that contribute to the smooth operation of vehicles, equipment, and machinery that rely on ethanol-blended gaso-line. By using high-quality hoses that meet industry standards and regulations, operators can ensure safe and reliable fuel transfer, minimize the risk of leaks or spills, and support sustainable fuel use practices. Proper installation and maintenance of fuel ethanol gaso-line hoses are essential to ensure their optimal performance and longevity. Regular inspections, checks for leaks or damages, and timely replacements when necessary are recommended to prevent potential hazards and maintain the integrity of the fuel system.Product Parameters

Fuel Ethanol Gaso-line Hose Specifications
Product Name	Fuel Ethanol Gaso-line Hose
Keywords	Auto Rubber Hose
Model	SAE J30R7
Length	Customized
Application	Fuel Ethanol Gaso-line
Color	Black or Customized
Working Pressure	10 - 35 bar or Customized
Working Temperature	- 40 Celsius to +125 Celsius
Certificate	ISO/TS 16949:2009
Size(mm)	4/4.8/6.4/7.9/9.7/12.7/16.0/19.1/22.0/25.4/31.8/38.1/45.0/50.8/60
Material	Rubber
Weight (kg/m)	0.12-1.82 or Customized
Bending Radius	40-700
Surface	Smooth Surface
MOQ	100 Meters

SIZE I.D			O.D	W.P		B.P		B.R	L	WT
dash	inch	mm	mm	bar	psi	bar	psi	mm	m/roll	kg/m
-2	5/32"	4.0	9.1	35	500	140	2000	40	50-100	0.12
-3	3/16"	4.8	10.3	35	500	140	2000	40	50-100	0.15
-4	1/4"	6.4	13.0	28	400	112	1600	45	50-100	0.16
-5	5/16"	7.9	14.6	28	400	112	1600	65	50-100	0.19
-6	3/8"	9.7	16.5	28	400	112	1600	80	50-100	0.24
-8	1/2"	12.7	20.4	28	400	112	1600	100	50-100	0.32
-10	5/8"	16.0	23.6	24	350	96	1440	160	50	0.39
-12	3/4	19.1	27.6	21	305	84	1218	190	50	0.52
-14	7/8"	22.0	31.0	20	300	80	1200	220	50	0.60
-16	1"	25.4	34.5	17.5	250	75	1000	250	50	0.66
-20	1.1/4"	31.8	42.5	15	215	60	860	320	40	1.05
-24	1.1/2"	38.1	48.5	12	175	48	750	420	40	1.25
-28	1.3/4"	45.0	55.0	10	145	40	580	500	40	1.45
-32	2"	50.8	62.0	10	145	40	580	630	40	1.65
38	2.3/8"	60	70.0	10	145	40	580	700	20	1.82

Detailed Photos
Company Profile
FAQ
Q1. How can we guarantee quality?
A1.Always a pre-production sample before mass production.
Always final Inspection before shipment.
Q2. What is your sample policy?
A2.We can supply the sample if we have ready parts in stock, but the customers must pay for the sample and courier costs.
Q3. Can you produce according to the samples?
A3: Yes, we can produce your samples or technical drawings. We can build the molds and fixtures.
Q4. Why should you buy from us not from other suppliers?
A4.For many years, we have been committed to the research and development of rubber and plastic products. Our R&D team has over 20 years of R&D experience. All of our products are produced directly from the factory. We accept OEM and ODM!
Q5.What are your main products?
A5.Our main products are all kinds of rubber hoses including Hydraulic hoses, air hoses, welding hoses, sandblast hoses, suction and discharge rubber hoses, and PVC hoses, including PVC Lay flat Hose,
Q6. Could we pay a visit to your factory?
A6.Yes, you are always welcome to visit our factory.
