Sv600 Online Acoustic Imaging Device

Product Description

Product Description
With its sophisticated audio sensors, SV600++can be installed near any equipment or asset, anywhere on the production line, and in areas with restricted or dangerous personnel access, ensuring that you can monitor critical parts of your facility without interference.
As an online automation solution, SV600+can be integrated with the manufacturing process, eliminating the need for lengthy troubleshooting processes such as soap water testing as an alternative to product leak detection. By continuously monitoring the operating environment of your device, you can quickly detect and repair gas leaks, thereby reducing the consumption of compressed gas and energy to help save costs Detailed Photos
With the powerful SoundMap ™ Technology, SV600 can convert the sound it "hears" into visual images, allowing you to quickly locate and quantify problem areas. In order to further understand product quality or safety issues, and to quickly detect changes in the entire compressor, pump, pipeline, conveyor belt and other devices.
In addition to 24/7 remote monitoring, SV600 can also be seamlessly integrated into factory systems and establish user-defined alarm conditions to alert users when sound characteristics change, even for hard to reach parts of the equipment.
As a predictive maintenance system, it can continuously monitor and detect mechanical abnormalities (such as bearing wear) in a timely manner before faults occur, ensuring the normal operation of your process flow.
Product Parameters
High end all-weather acoustic imaging monitoring
64 bit MEMS microphone located in Sunflower array
Powerful onboard real-time processor
Powerful onboard real-time processor
Sound classification
Frequency filtering
Decibel value and sound intensity mapping
Event triggered
Ethernet communication interface with 8-wire M12 fieldbus or RJ45 connector
Power over Ethernet (POE)
Protection level IP54
I/O support can be obtained through fieldbus connectors
