Megarevo 3 Phase Solar Inverter 500Kw 220V Dc 220V Ac Output Hybrid Passive Inverter

Product Description

Product Description>Highly integrated, easy to deploy, shorten the installationand debugging time.
>Internal integration of PV/ storage / PCS equipment, moreunified bus control, increased system stability.
>Easy expansion, support PV flexible confiquration.
>EMS functions are integrated into hybrid inverter, improvethe economic benefits of the system.
>Support unattended, improve the operation andnaintenance efficiency of the operator.
1. Self Consume
Photovoltaic gives priority to power the user load, and excess solar energy charges the batteries.When the battery is fully charged, the excess power can flow to the grid or photovoltaic limited power operation.Self-use mode is the most popular choice.
2. Battery First
PV gives priority to charging batteries, and the excess power will supply the user load.When the PV power is insufficient to supply the load, the grid will supplement it. The batteries are fully used as backup power.
3. Mixed Mode
The time period of mixed mode (also known as "economic mode") is divided into peak period, normal period and valley period.The working mode of each time period can be set through the electricity price of different time periods to achieve the most economical effect.

Model	MPS0030	MPS0050	MPS0100	MPS0150	MPS0250	MPS0500
AC(on-grid)
Max output power (kVA)	33	55	110	165	275	550
Rate output power (kW)	30	50	100	150	250	500
Rated voltage(V)	400
Voltage range (V)	320~460
Rated current (A)	43	72	144	216	361	722
Rated frequency (Hz)	50/60
Frequency range (Hz)	45~55/55~65
THDi	<3%
Power factor	1lagging-1leading(Settable)
AC connection	3W+N+PE
Transformer ratio	100/400	200/400	270/400	270/400	270/400	315/400
AC(off-grid)
Max output power (kVA)	33	55	110	165	275	550
Rated power (kW)	30	50	100	150	250	500
Rated voltage (V)	400
Rated current (A)	43	72	144	216	361	722
THDu	≤1% linear; or≤5% nonlinear
Rated frequency (Hz)	50/60
Overload capacity	110% long-term, 120% 1min
PV input
Max.PV input voltage (V)	1,000
Max.PV power (kW)	36/72	60/120	120/180/240	120/180/240	300/360	600/660/720
MPPT module quantity	1/2	1/2	2/3/4	2/3/4	5/6	10/11/12
MPPT voltage range (V)	250-850
MPPT voltage range@full load (V)	450-850
Battery
Battery voltage range (V)	250~850	320~850	420~850	420~850	420~850	500~850
Max. charging power (kW)	36/72	60/120	120/180/240	120/180/240	300/360	600/660/720
General data
Dimension W*D*H (mm)	800*800*1,900	800*800*1,900	1,200*800*2,050	1,200*800*2,050	(600*720*2,050)*1+1,200*800*2,050	(600*720*2,050)*2+1,600*1050*2,050
Net weight (kg)	576/607	720/750	1,120/1,150/1,180	1,250/1,280/1,310	1,980/2,010	3,265/3,295/3,325
Operation temperature (ºC)	-30 ~ 55
Relative humidity	0 ~95% non-condensing
Ingress protection	IP20
Noise emission (dB)	<70
Operating altitude	<5000m(>3,000 Derating)
Cooling	Air Cooling
Display and communication
Display	LCD touch-screen
BMS communication	RS485, CAN
EMS communication	RS485, TCP/IP
Certificates	EN62109-1/-2, EN62477-1, EN61000-6-2, EN61000-6-4, South Africa NRS097-2-1:2017,Pakistan & India IEC61727, IEC62116, IEC 61683

Packaging & Shipping
Compatible Lithium BatterySunpal Stacked Lithium Battery * Strong Expansibility: Support 16 modules in parallel*Stronger Compatibility: Cover all mainstream protocols and match most mainstream inverters 1C discharge*Long Life: 4 times long static and 8 consistency screening make the battery more durable*Safety & Reliability: Nano-coating and self-healing technology construct the LFP channel to add a firewall to the batterySunpal HV Lifepo4 Battery*Quick Customization of Electricity*Patented Modular Plug Design*Easy Installation Flexible Expansion*Emergency-Backup and Off-Grid Functionality*Long cycle life 6000 cycles*Safety first Smart BMS system
