LC APC Upc Sm 12 Core Bundle Fan-out Fiber Optic Pigtail

Product Description

ZSINE OFC Optical Fiber 12/24 Fibers LC Multimode Bunch Fiber Optic PigtailWe are professional fiber optic cable manufacturer.
Welcome to go to the factory !
Send message to our can get free samples.
Product Description
Features:Made by cold roll steel, electrostatic powder spraying.
PC material top transparent cover, easy to observation and maintenance.
Application:1.FTTH (Fiber To The Home)2.Optical fiber data communication3.Optical fiber access networks4.Optical fiber communications system5.Telecommunications
Product Parameters

Item	SC/APC (LC, FC, ST, E2000, MU, DIN optional)
Cable type	12cores LSZH
Cable jacket OD(mm)	0.9mm
Cable length	2M (1M,1.5M,3M,… optional)
Mode	SM (singlemode)
Fiber type	G652D/G657A1/G675A2
Cable color	Blue, orange, green, brown, gray, white, red, black, yellow ,purple, pink, aqua
Operating wavelength(nm)	1310, 1550
Fiber diameter(um)	9/125
Endface type	PC	UPC	APC
Typical Insertion Loss(dB)	≤0.3	≤0.3	≤0.3
Return Loss(dB)	≥45	≥50	≥55
Exchangeability	≤0.2
Vibration	≤0.2

Packaging & Shipping
Company ProfileSince 2021, Hangzhou Zsine Optoelectronic Technology Co.,LTD has provided high quality fiber optic products and solutions for our customers in many industries, including broadband, telecom, data center, fiber laser, fiber sensor, on-line monitoring, medical equipment, aerospace and defense.Our ProductsFiber Optic Splitter (FBT Splitter, PLC Splitter, Filter Splitter)WDM (Fused WDM, Filter WDM, CWDM, DWDM, OADM)Micro-optic Devices (Optical Isolator, Optical Circulator)Fiber Optic Interconnect (Fiber Optic patch Cable, Fiber Adapter, Fiber Attenuator)Active Devices (SFP, SFP+, SFP28, QSFP+, QSFP28 optical module)
Certifications
Our Exhibition
FAQ1. Are you a manufacturer? What is your MOQ?
Yes, we are definitely a real manufacture in Hangzhou,China. we welcome sample order to test and check quality. Mixed samples are acceptable,We do not have MOQ,1 sample is available.
2. What is the lead time?
For usual products,We keep stock,could ship 1~3 days after PO.For big quantity and special products,Please check lead time with our sales.
3. How do you ship the goods and how long does it take arrive?
We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-7 days to arrive.
4. Which payment method do you accept?
We accept T/T, Paypal, cash and any method that we can negociate.
5. What is your warranty time ?
We provide 3 years warranty after Shipment.
6. How to place an order?
Please contact our sales representative or send us an inquiry we will contact you within 12 hours.
7. Could I use our own logo and label?
Yes, OEM service can be acceptable and design the unique label for your company.
8. What kind of Service can we enjoy buy from ZSINE OFC?
Arrange the shipping and delivery asap.
Inspect the quality carefully of your goods.
Good package avoice the damage of goods during shipping.
Make documents for you to do custom clearance, packing list and commercial invoice.
