AC Elevator Push-Button Control FUJI High Quality Export Wooden Case Panoramic Lift Sightseeing

Product Description

Various Glass Door Panoramic Observation Sightseeing Passenger Elevator
Decoration
Parameter table

Loading capacity	Rated speed	Door open type	Door opening size(W x H)mm	Car size (Ax B) mm	Hoist way size(AH x BH) mm	Machine room size
						PIT	OH	(W x D x H)mm
450kg	1.0/1.5 /1.75	Center	800x2100	1400x850	2000x1550	1500/1600	4500	2500x3200x2500
630kg	1.0/1.5 /1.75	Center	800x2100	1400x1100	2000x1750	1500/1600	4500	2500x3600x2500
800kg	1.0/1.5 /1.75	Center	800x2100	1400x1350	2000x2000	1500/1600	4500	2500x3800x2600
1000kg	1.0/1.5 /1.75	Center	900x2100	1600x1400	2200x2150	1500/1600	4500	3000x4000x2600
1250kg	1.0/1.5 /1.75	Center	1100x2100	2000x1400	2600x2150	1500/1600	4500/4700	4000x4500x3000
1350kg	1.0/1.5 /1.75	Center	1100x2100	2000x1500	2600x2250	1500/1600	4500/4700	4000x4500x3000
1600kg	1.0/1.5 /1.75	Center	1100x2100	2000x1750	2600x2500	1500/1600	4500/4700	4000x4500x3000

Super enjoyment of mobile scene
Fine and exquisite observation elevator enhances building grade.It gighlights the whole building.
FUJI observation elevator is a mobile scene.It has fine and exquisite visual aesthetics,perfect and comfortable travel.It applies modern new material and new fully computerized,vector type variable frequency speed regulation(VVVF) control technology.It combines with data netmork system,modular structure,the latest machining craft&technoligy.
Various types of cars are available for your choice and can meetdifferent needs.The black deepening line in the picture are transparent glass.
Sightseeing Elevator
A vertical elevator powered by a motor, equipped with a box-like pod, used in multistory buildings to transport people or goods. One or several sides of the shaft wall and car wall are transparent materials, passengers in the elevator ride, can see the car outside the scene.
The shaft and car wall have at least one side transparent, passengers can see the car outside the scene of the elevator. It is mainly installed in hotels, shopping malls and high-rise office buildings, with transparent materials on one or several sides of the well wall and the same side of the car wall. Passengers can watch the scene outside the car while riding in the elevator.
At present, there is no need to dig bottom pit and self-built screw sightseeing elevator in the market. The design is simple and beautiful. This kind of elevator has no special requirements on civil construction.

Functional features
Advanced control technology
Universal design for passenger convenience
All measures are taken to provide a safer and more comfortable ride for all elevator passengers
Eye-catching display and door button
Voice prompt system
Highly sensitive button
Humanized handrail
Super enjoyment of mobile scene
Fine and exquisite observation elevator enhances building grade. It highlights the whole building.
FUJI observation elevator is a mobile scene.It has fine and exquisite visual aesthetics,perfect and comfortable travel.It applies modern new material and new fully computerized,vector type variable frequency speed regulation(VVVF)control technology.It combines with data network system,modular structure,the latest machining craft&technology.
FUJI observation elevator series applies the most advanced elevator tech, modern new materials,the latest machining tech.Therefore
it always has perfect play in the adpects of running quality,safety functions,car model design,energy-saving,loss-reducing etc.Observation elevator series has specially designed caroutline,distinguished and extraordinary decoration,It brings out the best from the building.Panorama glass with extra-wide angle of vision.extremely high perspective grants you to fully enjoy infinite demeanor of modern city.Meanwhile,you experience a pleasant journey.
The outstanding design of FUJI products can be shown in specially-thickened firm car wall,fine and magical internal car decoration,wear-resistant operation press-keys.highly clear display system etc.
