DN50pn1.0 High Quality PE Pipe for Water Supply

Product Description

High Density Polyethylene Pipe

Material: PE100,
Characters of pipe:
1, Light weight, long service life
The weight of HDPE pipe is one eighth that of steel pipe, while its service life is 8-10 times more than steel pipe.
2, Good anti-corrosion, good wear-resistance, anti-aging.
HDPE pipe has great corrosion resistance. It has good impact and pressure resistance performance, so it is widely used in piping project under different conditions.
3, High-toughness
It is not easy to break when suffer with the impact of the internal and external force, and it can be bent under water,and excellent anti-wave.
The concave-convex is within 30°of area, can be connected directly on land.
4, Low noise in media transportation.
Smooth surface, low resistance of fluids, low noise.
5, Easy installation
They are convenient to install and need no anti-corrosion treatment or welding work, which can reduce installation difficulty and save lots of working expenses under complex or special environment.
Applications:
1. Dredging Industry: Floating dredge pipe for river channel/sea shore/lake/pond, sand sunction/slurry dredge,
2. To transport natural gas & coal gas,
3. Food & chemical industry,
4. To transport ore & mud,
5. To replace cement pipe, cast iron pipe & steel pipe,
6. Landscaping pipeline,
7. City and town water supply
Specifications:

Outer Diameter of Pipe	Standard
	SDR26	SDR21	SDR17	SDR13.6	SDR11
	Working Pressure
	6 bar	8 bar	10 bar	12.5 bar	16 bar
mm	Wall Thickness ( mm )
32	-	-	-	-	3
40	-	-	-	-	3.7
50	-	-	-	-	4.6
63	-	-	-	4.7	5.8
75	-	-	4.5	5.6	6.8
90	-	4.3	5.4	6.7	8.2
110	4.2	5.3	6.6	8.1	10
125	4.8	6	7.4	9.2	11.4
140	5.4	6.7	8.3	10.3	12.7
160	6.2	7.7	9.5	11.8	14.6
180	6.9	8.6	10.7	13.3	16.4
200	7.7	9.6	11.9	14.7	18.2
225	8.6	10.8	13.4	16.6	20.5
250	9.6	11.9	14.8	18.4	22.7
280	10.7	13.4	16.6	20.6	25.4
315	12.1	15	18.7	23.2	28.6
355	13.6	16.9	21.1	26.1	32.2
400	15.3	19.1	23.7	29.4	36.3
450	17.2	21.5	26.7	33.1	40.9
500	19.1	23.9	29.7	36.8	45.4
560	21.4	26.7	33.2	41.2	50.8
630	24.1	30	37.4	46.3	57.2
710	27.2	33.9	42.1	52.2	--
800	30.6	38.1	47.4	58.8	--
900	34.4	42.9	53.3	--	--
1000	38.2	47.7	59.3	--	--
1200	45.9	57.2	70.6	--	--
Other Sizes of HDPE Pipe can be made upon request
