Ck5112D Single Column CNC Vertical Lathe Machine
| US$50,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
CK5112D
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
/
Control Method
/
Numerical Control
CNC/MNC
Processing Precision
/
Performance Classification
High-End CNC Machine Tools
Certification
CE
Transport Package
Carton Packing
Specification
/
Trademark
DMTG
Origin
Liaoning
Production Capacity
10 Sets/Month
Product Description
Hot Selling Vertical CNC Lathe Machine With Factory Direct Sale Price| Item | Unit | CK5112D | CK5116D | CK5120D | CK5123D | CK5125D | CK5126D | CK5131D |
| Max. cutting dia. | mm | 1250 | 1600 | 2000 | 2300 | 2500 | 2600 | 3100 |
| Max. cutting height | mm | 1000/1200 | 1000/1200/1400 | 1250 | 1350 | 1600 | 1600/2000 | 1600 |
| Loading weight | T | 3.2 | 5 | 8 | 8 | 10 | 10 | 10 |
| Worktable dia. | mm | 1000 | 1400 | 1800 | 2000 | 2250 | 2250 | 2830 |
| Worktable speed range | rpm | 6.3-200 | 5-160 | 3.2-100 | 3.2-100 | 2-63 | 2-63 | 0.5-63 |
| Worktable Step Range | --- | 4 gear shift stepless / 11 gearshift stepless | ||||||
| Worktable max. torque | N.m | 25000 | 32000 | 32000 | 32000 | 35000 | 35000 | 40000 |
| Vertical tool head cutting force | N | 20000 | 25000 | 25000 | 25000 | 25000 | 25000 | 30000 |
| Vertical tool head vertial travel | mm | 650 | 800 | 800 | 800/1000 | 800/1000 | 1000/800 | 1250 |
| Vertical tool head horzontal travel | mm | 700 | 1050 | 1190 | 1320 | 1420 | 1500 | 1900 |
| Turret rapid travel speed | mm | 20000 | ||||||
| Tool bar size | mm | 32*32/40*40 | 32*32/40*40 | 32*32/40*40 | 32*32/40*40 | 40*50/32*32 | 40*50/32*32 | 40*50/32*32 |
| Cross beam travel | mm | 650/850 | 650/850/1050 | 850 | 1000 | 1200 | 1200/1600 | 1250 |
| Crossbeam lifi speed | mm/min | 440 | ||||||
| Machining precision | --- | IT7 | ||||||
| Positioning precision | mm | 0.03 | ||||||
| Repositioning precision | mm | 0.015 | ||||||
| Main motor | kw | 22 | 30 | 30 | 30 | 37 | 37 | 55 |
| Machine weight | t | 8.5/9.5 | 12.4/14/14.8 | 17 | 18 | 24 | 24/26 | 30 |
| Overrall dimension (L*W*H) | mm | 2360* 2280*2800 | 2830* 2670*3010 | 3200* 2800*3250 | 3210* 2850*3300 | 3300* 4000*3500 | 3300* 4000*3500 | 4400* 4000*3800 |
