20PCS Disk Tractor Trailed Heavy Duty Disc Harrow with Low Price
Basic Info.
Model NO.
1BZ-2.2
Color
Red
Condition
New
Power Type
Diesel
Applicable Industries
Farms
Working Width
2.2m
Use
Tilling
Dimension(L*W*H)
Standard Size
Model
1bz-2.2
Weight
1250 Kg
Diameter of Disc
660 X5 mm
Transport Package
Iron Case
Trademark
ZEYI
Origin
Shandong, China
HS Code
8432210000
Production Capacity
120 Set/Sets Per Month
Product Description
Product Description1BZ series heavy-duty offset disc harrow are mainly used for cleaning away stuble of plants before tillage,or crushing clods after tillage on uncultivated land and in stickly heavy clay soil fields,they can also be used as a plough for primary tillage in dry cultivated fields.The series products are all fitted with hydraulic rubber wheel for transportation,It is easy to be transported and chang directiong on the edge of fields.
| Model | 1BZ-2.2 | 1BZ-2.5 | 1BZ-3.0 | ||||
| Diameter of disc | 660 mmX 5 | ||||||
| Weight | 1250 | 1350 | 1430 | ||||
| Working width (m) | 2.2 | 2.5 | 3 | ||||
| Working depth (cm) | 180-200 | 180-200 | 180-200 | ||||
| Ground clearance (cm) | >160 | >160 | >160 | ||||
| Maximum working angle | 23 | 23 | 23 | ||||
| Nos of disc blade | 20 | 24 | 28 | ||||
| Matched power (hp) | 80 | 80 | 100 | ||||
| Model | 1BZ-3.4 | 1BZ-4.0 | 1BZ-5.3 | ||||
| Diameter of disc | 660 mmX 5 | ||||||
| Weight | 1550 | 1650 | 1780 | ||||
| Working width (m) | 3.4 | 4 | 5.3 | ||||
| Working depth (cm) | 180-200 | 180-200 | 180-200 | ||||
| Ground clearance (cm) | >160 | >160 | >160 | ||||
| Maximum working angle | 23 | 23 | 23 | ||||
| Nos of disc blade | 32 | 36 | 48 | ||||
| Matched power (hp) | 120 | 120 | 140 | ||||
