Newton Hardness Tester Pen HT-6510NT Range 0~20N~40N

Product Details

Product Description

Product Description
Hardness Tester HT-6510NT
Applications:
It can accurately measure and record hardness of various things (e.g., the hardness of coatings, plastics, wood, or metal materials).
Features:
* The measured surface can be flat or curved.
* Not limited by area size.
* Easy to operate, stable performance.
* Easy to carry and other characteristics.
Principle:
The spring compression deformation, the force generated by the load on a known diameter of the test head, with the test head to mark the coating surface to be tested to check whether the coating surface is damaged, the test results in Newton.
Details:
Pressure test spring material:Spring steel
Test head material:Tungsten carbide
Test head diameter:
0.5mm (Opel, optional)
0.75mm (Bosch, standard)
1.0mm(optional) (conforming to IS01518 and DEF)
Spring pressure range:
0~3N (marked in blue)
0~10N (marked in red)
0~20N (yellow mark)
0~40N (white mark), (optional)
