Graphite Plate/Flexible Graphite Paper/Graphite Roll

Product Description

Flexible graphite foil graphite tape graphite winding tape Spiral wound gasket graphite tape/Graphite Foil

The graphite strip of spiral wound gasket is cut into strips by special tools of high-precision CNC lathe. Compared with the traditional graphite strip, the precision is higher, the damage to the graphite strip is smaller, and the cutting part is smooth without burr, so it is used to produce the graphite spiral wound gasket filling material.

Performance features:
1. Excellent heat resistance and cold resistance.
2. Excellent chemical resistance.
3. Good self lubrication.
4. High rebound rate.
5. Easy to use and low cost.
Applicable medium of winding pad graphite tape:
Hot water, high temperature, high pressure, steam, heat exchange medium, ammonia, hydrogen, organic solvent, hydrocarbon, low temperature liquid, etc.

Common specification and size of graphite tape for winding pad:
Thickness: 0.5 ~ 1.0mm
Width: 5.6-6.0mm, 3.9-4.5mm for 4.5mm and 3.2mm respectively,
Main performance parameters of winding pad graphite Foil/ Belt :

(Item)	Value
(C concentration)	99%
(S concentration)	<1000ppm<>
(chlorine concentration)	<45ppm
( tensile strength)	4.5MPa
(compressibility)	>40%
(recovery)	>10%
(Temperature)	-200ºC-600ºC
(Pressure)	20MPa
(Terence of Thickness)	-0.04mm~+0.04mm
(Terence of Dimension)	According the Gasket size
(Terence of Density)	-0.06~g/cm3+0.06gcm3

Products Show Times :

Xingshi Graphite and Carbon , Welcome your inquiry !- Your trusted Chinese Supplier !
XINGSHI GRAPHITE PAPER/SHEET /ROLLS FEATURES AND ADVANTAGES:
Extension Applications :
For : For( Ideal Thermal Management /Heat-sinking material) :
Smart Phones ,Mobile phones ,DSC ,DVC ,Tablet PCs,Pcs , LED Devices Semiconductor manufacturing equipment (Sputtering,Dry Etching Steppers) Optical communications equipment
Or For (Ideal sealing material for high-temperature applications): Gaskets material in automotive ,petroleum and chemical ,paper ,nuclear industries Thermal barrier at high temperature to provide outstanding reflectivity Fuel cell industry for bipolar plates Excellent for sealing high temperature valves ,shafts and flanges Excellent lining and protective layer for vessels containing hot or corrosive fluids
