White Fire Hose PVC/TPU Rubber Coated Fire Hose (Multiple Size Options)

Product Description

Product Description
1-1/2 30m UL Certification Approval 14bar NBR Nitrile Rubber Covered Fire Hose with BS336 Coupling
Description Constructions:
Inside:very smooth for minimum friction loss nitrile/pvc(70/30),tpu,pvc lining
Reinforcement:Reinforced with Jacket of 100% high tenacity polyester yarn,circular woven.
Outside:Nitrile/PVC,TPU,PVC Cover with longitudinal ribs for excellent abrasion resistance
Features:
High quality Nitrile/PVC compound is forced through the jacket in the extrusion process. Exceptionally resistance to scrubing. Easy to maintain and easy to handle. Completely resistant to oil&ozone(Nitril/PVC&TPU),suitable for many chemicals(Nitril/PVC&TPU) Resistance to high temperature(Nitrile/PVC) Minimum friction loss because of very smooth inner lining Excellent Abrsion assitance(TPU>Nitrile/PVC>PVC Application:Fire fighting,shipping, petroleum,Agriculture,Mining, Garden.
Color:White,yellow, red, or as customer's instruction
Standard:UL,FM,MED,EN14540,UNI9487,NFPA, or as customer's requirements.
Length:10-40M
Technica Data Sheet

Diameter		Working Pressure			Burst Pressure
Inch	mm	BAR	MPA	PSI	BAR	MPA	PSI
1"	25	13 to 25	1.3 to 2.5	190 to 365	39 to 75	3.9 to 7.5	570 to 1090
1-1/4"	32	8 to 25	0.8 to 2.5	120 to 365	24 to 75	2.4 to 7.5	350 to 1090
1-1/2"	38	8 to 25	0.8 to 2.5	120 to 365	24 to 75	2.4 to 7.5	350 to 1090
1-3/4"	44	8 to 25	0.8 to 2.5	120 to 365	24 to 75	2.4 to 7.5	350 to 1090
2"	51	8 to 25	0.8 to 2.5	120 to 365	24 to 75	2.4 to 7.5	350 to 1090
2-1/2"	64	8 to 25	0.8 to 2.5	120 to 365	24 to 75	2.4 to 7.5	350 to 1090
2-3/4"	70	8 to 25	0.8 to 2.5	120 to 365	24 to 75	2.4 to 7.5	350 to 1090
3"	75	8 to 25	0.8 to 2.5	120 to 365	24 to 75	2.4 to 7.5	350 to 1090
4"	102	8 to 16	0.8 to 1.6	120 to 235	24 to 48	2.4 to 4.8	350 to 700
5"	127	8 to 13	0.8 to 1.3	120 to 190	24 to 39	2.4 to 3.9	350 to 570
6"	152	8 to 13	0.8 to 1.3	120 to 190	24 to 39	2.4 to 3.9	350 to 570

Approved fire hose
Production Workshop

Hot Products
Company Profile
Packaging & Shipping
Shipping Different amount of time will be required for difference FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in plastic bags for inner package.Out package you could choose the carton box or woven bags.
Q2. What is your terms of payment?
A: T/T ,30% In Advanced, and 70% Before delivery,Or L/C. The pictures of products detials and packages will be sent before you pay the balance.
Q3. What is your terms of delivery?
A: FOB, CFR, CIF.
Q4. How about your delivery time?
A: Generally, it will take within 10 to 30 days as receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the courier cost.But the delivery charges will be deducted from the customer's future order.
Q6. Do you test all your goods before delivery?
A: Yes,we have three inspection steps to make sure the products you received in high quality.
Q7: Are you accept the OEM?
A: Yes,we support the OEM or ODM.
Q8: Our port of shipment?
A: Qingdao,China or as your request.
