Diesel Burner Spray Booth / Customzied Paint Booth D7006GS
| US$5,500.00-9,800.00 | 1 Set (MOQ) |
Basic Info.
Model NO.
D7006GS
Type
Spray Booth
Certification
CCC, CE, GS, SGS
Substrate
Sandwich Panel
Brand
Captain
Coating
Powder Coating
Airflow Direction
Fully Undershot-type
Heating Mode
Diesel
Paint Mist Treatment
Dry-type
Condition
New
Inside Dimension
6900mmx3900mmx2700mm
Outside Dimension
7000mmx5350mmx3400mm
Front Door
3-Folds:3000*2600mm, Front and Back Door
Personal Door
1-Fold: 750*1800mm
Wall Panels
50mm EPS, 0.4mm Steel, 14kgs Density
Ceiling Panel
0.8mm Galvanzied Steel Sheet
Air Intake
2 Set 4kw Centrifugal Fan
Air Exhaust
1 Set5.5kw Centrifuga Fan
Damper
Pneumatic
Heaeting
Diesel Burner
Basement
300mm High with 3 Row Diamond Plate 2 Rows Grids
Ramp
8 PCS, 630X1800mm Long
Ceiling Lights
32PCS LED Lights
Color
White, Red, Blue, Grey, Orange
Transport Package
Export Container /Pallet /Disassembly with Carton
Specification
6900mmX3900mmX2700mm
Trademark
OEM/Captain
Origin
Jiangsu, China.
HS Code
8424899990
Production Capacity
96sets/Month
Packaging & Delivery
Package Size
6900.00cm * 3900.00cm * 2700.00cm
Package Gross Weight
3960.000kg
Product Description
We are the manufacturer of different kinds of spray booth for 20 years , according to customers requirements , we can design the best solution for you , and show you the 3D drawing , then you can know more claerly about the spray booth /preparation bay / powder coating booth / baking oven you need .1. CE approved
2. German Technology
3. Professional European-style blower system
4. Spray booth professional manufacturer
5. Factory price, energy saving
6. High quality, best sell service, timely delivery
7. We can meet at customer's special requirement
Same quality, our price is lower.
Same price, our quality is better.
We supply 2 years warranty!
This model is our standard model,also we can design the booth according to your needs.Detailed Specifications
| Item | Detailed specification | |
| Inside dimension | 6900×3900×2700 mm(L×W×H) | |
| Outside dimension | 7000×5350×3400 mm(L×W×H) | |
| Front door | Front and back door , Folding door, each set with 3 folds, 3000×2600mm,(WxH), metal sheet, color : blue, red, white, orange | |
| Emergency door | 1 unit, 750×1800mm(W×H), color: white | |
| Basement | Galvanized steel assemble, 300mm high, quadrate steel support, 5 rows grilles made by flat bar and twisted steel, 8 ramps, 630×1800mm/pc. | |
| Wall panel | Thickness: 50mm, width:950mm, tongue and groove structure, 0.5mm color steel with EPS inside, color: white.blue.orange.red | |
| Light | Ceiling Lights: 8Units×4Pcs=32Pcs×16W, Side Lights: 8Units×2Pcs=16Pcs×16W, LED lights. The lighting boxes open outside, and with powder coating. illumination≥1200Lux | |
| Generator cabinet | Intake from back upper, exhaust from back upper, white coated steel outside covered, galvanized steel inside, filled with heat preservation material inside. | |
| Intake and Exhaust system | Inlet: 2×4KW centrifugal fan, air capacity: 22000 m3/h. | |
| Outlet: 1×5.5KW centrifugal fan, air capacity: 15000m3/h. | ||
| Heating system | RIELLO G20diesel burner, stainless steel heat exchanger, pneumatic damper actuates from spraying to baking cycle. Max. heating productivity: 200000Kcal/h. | |
| Spray to baking switch | Auto Pneumatic damper | |
| Chimney ducting | 304 Stainless ducting and one safe fireproof chimney elbow. | |
| Purification system | Pre-filter, ceiling filter, fiberglass filter, activated carbon filter | |
| Roof | 0.8mm Galvanized steel | |
| Control system | Spraying, heat spraying, baking, time setting, lighting switch, failure indicator, emergency stop, hour meter, temperature limit controller. | |
| Total power | 16 KW | |
Design drawing:
Real photos :
Materials
Production
Package and Delivery
Installation Draw
Installed Model
| Delivery time : after received you payment ,we will produce , for this standard model , the delivery time is 2-3 weeks . |
| Payment term: 50% TT IN ADVANCE , 50 % before delivery |
| After sales service : 2 years warranty for most parts (Consumables (eg filters) are not included) |
| when your workers unloading the goods, If they find something damaged during transit by sea, please take the pictures of the damage in the container and we will reissue you or give you some compensation. (Please note: The picture shows the damaged picture of the goods in the container, which is convenient for us to record) |
Also we can design the spray booth according to your need,so just tell me your needs,we can give you the best solution.
Captain Advantages
*The same price higher quality, the same quality lower price! ! !
*2 years quality warranty! ! !
*Fast and stable supply capability! ! !
*Personalized design to meet customer various needs! ! !
Professional team from design to installation! Warmly welcome to visit our factory!
