Aerosun Tower Equipment, Fertilizer, High Pressure
| Negotiable | 1 Piece (MOQ) |
Basic Info.
Model NO.
Tower
Type
Tower Reactor
Material
Stainless Steel
Capacity
>1000L
Structure
Filling Tube
Pressure
Positive
Agitator Model
Combined Agitator
Tower Reactor Type
Spray Tower Reactor
Heating
Outside (Inside) Coil Heating
Heat Transfer Structure
Inner Coil Type
Automatic Grade
Automatic
Condition
New
Transport Package
Naked
Specification
less than DN 5000
Trademark
Aerosun Corporation
Origin
China
HS Code
7311009000
Production Capacity
100PCS/Year
Product Description
Aerosun Corporation is a comprehensive company with design, manufacture and on-site installation capability. In addition, it has professional technical team, strict management mechanism, sophisticated processing equipment, perfect quality assurance system.Aerosun Corporation has A1,A2,C2-class pressure vessel design and manufacturing qualification which issued by the state quality and technical supervision bureau. It also has the US ASME U,U2 pressure vessel design and manufacturing license, HPO authorization certificate issued by the European standard pressure vessel.
AerosunAmmonia Synthesis Tower
Design pressure: 16/19.4/31.4MPa
Main material: SA387.Cr11.Cl2,Q345R,20MnMo,1Cr5Mo
Aerosun Urea Synthesis Tower
Design pressure: 15.6/21.56MPa
Main material: 19Mn6,15MnVRC,X2CrNi8143MoD/Q345R,316LMod
Aerosun Waste Heat Boiler
Design pressure: 16/31.4MPa
Main material: 0Cr18Ni10Ti/10MoWVNb
Global Reference
S/N | Descripation | Qty | Main Material | Dimension ID * TL-TL | Code | Project | Client Name |
| 1 | Feed Desulfurizer | 2 | SA516 Gr70 N/SA105/SA106 | ID1982×2642 | ASME + NB | Garyville USA | Air Products |
| 2 | HT Shift Reactor | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID3962×5715 | ASME + NB | ||
| 3 | Condensate Separator | 1 | SA516 Gr70+SA240 304L SA105+304L Clad | ID2134×6223 | ASME + NB | ||
| 4 | Condensate Stripper | 1 | SA516 Gr70+SA240 304L SA105+304LClad | ID1220×15469 | ASME + NB | ||
| 5 | Deaerator | 1 | SA516 Gr70/SA105 SA240 304L/SA182 304L | ID1830×6908 ID3658×6782 | ASME + NB | ||
| 6 | Blowdown Drum | 1 | SA516 Gr70/SA105/SA106 | ID742×1676 | ASME + NB | ||
| 7 | Oil Blowdown Drum | 1 | SA516 Gr70/SA105/SA106 | ID894×2134) | ASME + NB | ||
| 8 | Aqueous Ammonia Tank | 1 | SA516 Gr70/SA105/SA106 | ID2590×5791 | ASME + NB | ||
| 9 | Surger Drum | 2 | SA516 Gr70/SA105/SA106 | ID3658×33680 | ASME + NB | ||
| 10 | Surger Drum | 2 | SA516 Gr70/SA105/SA106 | ID3658×33680 | ASME + NB | Exoon Mobile USA | |
| 11 | PSA PSA Adsorber Vessel | 10 | SA516 Gr70 N/SA350 LF2 | ID3658×9754 | ASME + NB | ||
| 12 | Cold Proc.Gas Condensate Separator | 1 | SA516 Gr70+SA240 304L SA105+304LClad | ID2134×6223 | ASME + NB | ||
| 13 | High Temperature Shift | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID3962×5715 | ASME + NB | ||
| 14 | Hydrogenator Desulfuizer | 2 | SA516 Gr70 N/SA105/SA106 | ID2134×3302 | ASME + NB | ||
| 15 | MP MP STREAM DEAERATOR | 1 | SA516 Gr70/SA105 SA240 304L/SA182 304L | ID1524×7163 ID3200×6054 | ASME + NB | ||
| 16 | HP HP STREAM DEAERATOR | 1 | SA516 Gr70/SA105 SA240 304L/SA182 304L | ID2591×14630 | ASME + NB | ||
| 17 | Oil Blowdown Drums | 3 | SA516 Gr70/SA105/SA106 | ID898.4×2133.6 | ASME + NB | ||
| 18 | Instrument Air Reveiver | 1 | SA516 Gr70/SA105/SA106 | ID1524×3962 | ASME + NB | ||
| 19 | Service Air Receiver | 1 | SA516 Gr70/SA105/SA106 | ID898.4×2489.2) | ASME + NB | ||
| 20 | Aqueous Ammonia Tank | 1 | SA516 Gr70/SA105/SA106 | ID2590×5791 | ASME + NB | ||
| 21 | Hydrogenation | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID1829 × 4572 | ASME + NB | Detroit USA | |
| 22 | Feed Desulfuriz | 2 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID1829 × 7391 | ASME + NB | ||
| 23 | Hi Temp Shift | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID3048×4191 | ASME + NB | ||
| 24 | Prereformer | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID1981×3556 | ASME + NB | ||
| 25 | Feed Compressor Suction Drum | 1 | SA516 Gr70/SA105/SA106 | OD915 × 1981 | ASME + NB | ||
| 26 | Fuel Gas Knockout Drum | 1 | SA516 Gr70/SA105/SA106 | OD915 × 2130 | ASME + NB | ||
| 27 | Cold Process Gas Condensate Separator | 1 | SA240 304L/SA182 304L | ID1524 × 5283 | ASME + NB | ||
| 28 | Process Condensate Stripper Column | 1 | SA516 Gr70+SA240 304L SA105+304LClad | ID914 × 14808 | ASME + NB | ||
| 29 | Deaerator | 1 | SA516 Gr70/SA105 SA240 304L/SA182 304L | ID1830 × 7671 ID3658 × 6350 | ASME + NB | ||
| 30 | Aqueous NH3 Tank | 1 | SA516 Gr70/SA105/SA106 | ID2590 × 6250 | ASME + NB | ||
| 31 | RFG RFG Feed Gas Knockout Drum | 1 | SA516 Gr70N/SA105/SA106 | OD610 × 2058 | ASME + NB | ||
| 32 | Instrument Air Receiver | 1 | SA516 Gr70/SA105/SA106 | OD1548 × 3962 | ASME + NB | ||
| 33 | Glycol Tank | 1 | SA516 Gr70/SA105/SA106 | OD1544 × 4572 | ASME + NB | ||
| 34 | PSA PSA Adsorber Vessel | 10 | SA516 Gr70 N/SA350 LF2 | ID3658 × 9754 | ASME + NB + PED | Rotterdam Netherland | |
| 35 | PSA PSA Adsorber Vessel | 10 | SA516 Gr70 N/SA350 LF2 | ID3658 × 9754 | ASME + NB + PED | Luling, USA | |
| 36 | PSA PSA Adsorber Vessel | 4 | SA516 Gr70 N/SA350 LF2 | ID1676 × 6096 | ASME + NB | Thailand BIG | |
| 37 | PSA PSA Adsorber Vessel | 16 | SA516 Gr70 N/SA350 LF2 | ID3658 × 6884 | ASME + NB | Port Arthur USA | |
| 38 | H2 H2 Cleaner | 2 | SA240 316L/SA312 TP316L SA403 WP316L | ID1524 × 1702 | ASME + NB + DOSH | Malaysia SDN BD (20813 A) | |
| 39 | PSA PSA Adsorber Vessel | 4 | SA516 Gr70 N/SA350 LF2 | ID1219 × 6554 | ASME + NB + DOSH | Malaysia Kuantan HYCO Plant | |
| 40 | H2 H2 Cleaner | 2 | SA240 316L/SA312 TP316L SA403 WP316L | ID1524 × 1702 | ASME + NB +GB150 | Xia Men China | |
| 41 | PSA PSA Adsorber Vessel | 12 | SA516 70N / SA 350 LF2 / SA106B | ID3658 × 10363 | ASME + NB | Norco USA | |
| 42 | Hydrogenator Desulfurizer | 2 | SA516 Gr70 N/SA105/SA106 | ID2438 × 3175 | ASME + NB | ||
| 43 | Pre-Reformer | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID3048 × 5336 | ASME + NB | ||
| 44 | MT Shift Reactor | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID4267 × 7188 | ASME + NB | ||
| 45 | Shift Reactor Knockout Seperator | 1 | SA516 Gr70+SA240 304L SA105+304LClad | ID2744×3023 | ASME + NB | ||
| 46 | Cold Process Gas Condensate Sepeartor | 1 | SA516 Gr70+SA240 304L SA105+304LClad | ID2134 × 11227 | ASME + NB | ||
| 47 | Process Condensate Stripper Column | 1 | SA516 Gr70+SA240 304L SA105+304LClad | ID1372)×15596 | ASME + NB | ||
| 48 | DEAERATOR | 1 | SA516 Gr.70N / SA 240 2205 / SA105N / SA 182 F51 / SA106 Gr.B | (ID36586 / ID1830 )× 15748 | ASME + NB | ||
| 49 | Instrument Air Receiver | 1 | SA 516 Gr.70 / SA 105 SA Gr.106 B | ID1524×3963 | ASME + NB | ||
| 50 | Oil Blowdown Drum | 1 | SA 516 Gr.70 / SA 105 SA Gr.106 B | ID898×2134 | ASME + NB | ||
| 51 | Aqueous Ammonia Tank | 1 | SA 516 Gr.70 / SA 105 SA Gr.106 B | ID2591×5791 | ASME + NB | ||
| 52 | N2 Purifier Vessel | 2 | SA240 316L / SA312 TP316L | ID1524×1702 | ASME + NB +GB150 | Xi'an China | |
| 53 | CDA Buffer tank | 2 | 16MnDR / S30408 /S30408IV / 16MnD IV | ID3400×33500 | ASME + NB +GB150 | ||
| 54 | Hydrogenator Desulfurizer | 2 | SA516 Gr70 N/SA105/ SA 106 Gr.B | ID2438×3175 | ASME + NB + ABSA | Canada Saskatchewan | |
| 55 | Pre-Reformer | 1 | SA387.Gr11.Cl2/SA182.F11Cl2 | ID3048×6172 | ASME + NB + ABSA | ||
| 56 | MT Shift Reactor | 1 | SA387.Gr11.Cl2/SA182.F11.Cl2 | ID4267×5232 | ASME + NB + ABSA | ||
| 57 | 150-C502A/B Surge Tank | 2 | SA 516 Gr.70 / SA 105 / SA 106 Gr.B | ID3658 × 29108 | ASME + NB + ABSA | ||
| 58 | Cold Process Gas Condensate Sepeartor | 1 | SA240 304L/SA182 F304L/ SA312 TP304L | ID2134 × 6452 | ASME + NB + ABSA | ||
| 59 | Process Deaerator | 1 | SA240 304L/SA182 F304L/ SA312 TP304L | (ID2438 / ID1219 )× 16358 | ASME + NB + ABSA | ||
| 60 | EXPORT STEAM DEAERATOR | 1 | SA516 Gr.70N / SA240 304L / SA 350.LF 2 CL.1 / SA182 F304L/ SA106 Gr.B | (ID3353 / ID1829)× 16358 | ASME + NB + ABSA | ||
| 61 | Instrument Air Receiver | 1 | SA 516 Gr.70 / SA 105/ SA 106 Gr.B | ID1372 × 3277 | ASME + NB + ABSA | ||
| 62 | Oil Blowdown Drum | 1 | SA 516 Gr.70 / SA 105/ SA 106 Gr.B | ID610 × 1524 | ASME + NB + ABSA | ||
| 63 | Process steam blowdown drum | 1 | SA516 Gr.70N / SA105N / SA106 Gr.B | ID1220 × 2438 | ASME + NB + ABSA | ||
| 64 | Export steam blowdown drum | 1 | SA516 Gr.70N / SA105N / SA106 Gr.B | ID1220 × 2438 | ASME + NB + ABSA | ||
| 65 | PSA PSA Adsorber Vessel | 10 | SA516 70N / SA 350 LF2 / SA 106 Gr.B | ID2286 × 7925 | ASME + NB | Mont Belvieu USA | |
| 66 | 150-C502 Surge Tank | 1 | SA 516 Gr.70 / SA 105/ SA 106 Gr.B | ID3658 × 13868 | ASME + NB | ||
| 67 | PSA PSA Adsorber Vessel | 4 | SA 516 Gr.70 / SA 105/ SA 106 Gr.B | ID1067 × 5486 | ASME + NB | Thailand BIG | |
| 68 | PSA PSA Adsorber Vessel | 3 | SA516 70N / SA 350 LF2 / SA 106 Gr.B | ID2438 × 6492 | ASME + NB | Geismar,LA | |
| 69 | PSA PSA Adsorber Vessel | 3 | SA516 70N / SA 350 LF2 / SA 106 Gr.B | ID1524 × 6248 | ASME + NB | Helium3 Rasgas | |
| 70 | V021 V021 Surge Tank | 1 | SA 516 Gr.70 / SA 105 / SA 106 Gr.B | ID3048 ×12192 | ASME + NB | ||
| 71 | PSA PSA Adsorber Vessel | 10 | SA516 70N / SA 350 LF2 / SA 106 Gr.B | ID3658 × 10363 | ASME + NB | Baytown | |
| 72 | Water tank | 2 | SA515-70 / SA 105 / SA 106 Gr.B | DN1800×9800 | ASME + NB | Leyth Geothermal | The Philippines national petroleum energy development company |
| 73 | Flash evaporator | 8 | SA515-70 / SA 105 / SA 106 Gr.B | DN2560/DN1280×7890 | ASME + NB | ||
| 74 | Hydrotreating reactor | 3 | SA515-70N/SA240-TP304 | DN1000×4000 | ASME + NB | Kolon Chemical Corporation PR-10 | Hyundai Engineering Co.,Ltd |
| 75 | Tail gas separator | 21 | SA515-70N/SA240-TP304 | DN1300×5300,etc | ASME + NB | ||
| 76 | Mineral main fractionator | 5 | SA516-70 | DN1350×60000 | ASME + NB | ||
| 77 | Condenser | 10 | SA516-70/SA179 | DN600×5050 ,etc | ASME + NB+TEMA | ||
| 78 | Condenser | 15 | SA516-70/SA179 | DN500×2840,etc | ASME + NB+TEMA | ||
| 79 | Light shunt cans layer | 5 | SA240-304 | DN2000*34900 | ASME + NB | AAI | Mitsubishi Heavy Industries, LTD |
| 80 | HTS HTS tank | 5 | SA515-70 | DN4000*12500 | ASME + NB | ||
| 81 | Absorption tower | 17 | SA240-304 | DN2000/3100*43000, etc | ASME + NB | ||
| 82 | Reboiler | 4 | SA240-304/SA213-TP304 | DN1200*6062 | ASME + NB+TEMA | ||
| 83 | Condenser | 15 | Q235-A/SA213-TP304 | DN1100*6175,etc | ASME + NB+TEMA | ||
| 84 | Condenser | 15 | Q235-A/SA213-TP304 | DN850*5635,etc | ASME + NB+TEMA | ||
| 85 | Long-term dry gas tank | 16 | 0Cr19Ni9 | DN2200*6677 | GB150+JC334 | Shanghai Dye | BASF-YPC Company Limited,Germany |
| 86 | Braising dry gas tower | 12 | 0Cr19Ni9 | DN5030*48404 | GB150+JC334 | ||
| 87 | Alcohol storage tower | 2 | SA516 Gr.70 /SA105/ SA106/SA662 GrC | DN2900*28*11600,etc | ASME + NB | SMAG, Singapore | Mitsui Engineering &Ship Building Co.,Ltd |
| 88 | Mixer | 39 | SA516 Gr.70 /SA105/ SA106/SA662 GrC | DN3000*32*11205,etc | ASME + NB | ||
| 89 | Ester storage tank | 73 | SA516 Gr.70 /SA105/ SA106/SA662 GrC | DN2900*26*11622,etc | ASME + NB | ||
| 90 | WATER K.O.DRUM | 3 | 16MnR+304 | DN1950*3000 | DITTO | Maoming EO/EG | |
| 91 | Waste gas separator | 3 | 16MnR | DN2200*19000 | DITTO | ||
| 92 | Buffer tank | 4 | 16MnR | DN3600*13740 | DITTO | ||
| 93 | Waste gas processor | 4 | 0Cr18Ni9 | DN1500*18000 | DITTO | ||
| 94 | -1 Vinyl-1 storage tanks | 4 | 16MnR | DN4000*19940 | DITTO |
