Bt50 Bt40 Fully Automatic Universal Angle Milling Swivel Boring Head for Bevel Hole Processing

Product Description

Δ Wide range of product types;
Δ Short production cycle, fast delivery, long service life, high product accuracy;
Δ Strong packaging;
Δ Logistics can be specified;
Δ Can be customized;
we have many types of milling heads, including manual, semi-automatic, fully automatic, heavy duty milling heads, flat right angle milling heads and so on. If you need, please contact us!
Applicable Equipment: Gantry Machining Center, Floor Boring Machine, Planer Boring Machine;
Purpose: Expanding the processing range of equipment;
Specificities: Automatic gripping milling head with locking disk, c-axis can be automatically indexed (1"2.5", 5°), no need to hit the table to check, improve efficiency.
Optional Features: a-axis automatic indexing (1°, 2.5°, 5').

Gear ratio r	1:1
Tool interface	ISO 50
Maximum speed rpm	2000
Maximum power KW	37
Torsion Nm	1200
selectable
Connection method	Automation
A/C axis rotation method	Automation
A/C axis indexing and positioning method	End gear disk positioning (144 teeth/2.5° or 72 teeth/5°)
Drawing method	Automation

High quality accessories
Main shaft: high stiffness, high precision, small deformation, low noise, good axial stability and good dynamic performance.
Bevel gear: made of high-strength low carbon alloy steel by carburizing and quenching, with grinding process, high precision, good contact, high load carrying capacity and long life.
End gear disk: input BT40/BT50, output can be clamped BT30/BT40/BT50 any style of shank.
Δ Manual Angle Milling Head
Δ Fully automatic angle milling head
Δ Semi-automatic universal milling head
Δ Semi-automatic extended flat angle milling head
Δ Manual angle dual output milling head
Δ Semi-automatic flat angle milling head WUXI GOLP CNC MACHINERY CO.,Ltd is located in Wuxi--the core location of the Changjiang Delta which is the most dynamic economy area in China. We are a new brand company specializing in the CNC machine tool industry. The company is mainly engaged in Die-casting machine, CNC Punching machines, Powder compacting machine and other new intelligent machine and related supporting products. The company adheres to the business philosophy --Professional quality, Credibility first, Customer first, and is committed to the development goal of becoming an important member of the global market in the field of intelligent machines.


Q: What are your normal lead times?
A: Normally, 30 to 60 days
Q: What kind of package do you offer?
A: Standard wooden case packing
Q: Do you have certification of your machine?
A: CE certificate
Q: How about the warranty service?
A: 24 months
Q: How about the installation and commissioning?
A: we will enclose the production specification with the machine, and we could provide the video online to you, and our engineers are available to debug machinery overseas.
Q: How to select the suitable machine?
A: Pls tell us the machine you need, Includes drawings, specifications and other requirements.
Q: How to do it if we meet the issue during the operation?
A: We provide completely after sales service, and our engineers are available to service machinery overseas.
Q: If we want to learn how to operate the machine, Can you provide it?
A: Yes, we have special service team which will offer you professional guidance.
