485modbus RTU Comunication Protocol Wire Tensiometer

Product Description

Schmidt Tension Meter:
Available Models

Model	Tension Range	Measuring Head Width*	SCHMIDT Calibration Material**
DX2S-50	10 - 50 cN	54 mm	PA: 0.12 mm Ø
DX2S-120	20 - 120 cN	54 mm	PA: 0.12 mm Ø
DX2S-200	20 - 200 cN	54 mm	PA: 0.12 mm Ø
DX2S-400	20 - 400 cN	54 mm	PA: 0.20 mm Ø
DX2S-1000	50 - 1000 cN	54 mm	PA: 0.30 mm Ø
DX2S-2000	200 - 2000 cN	116 mm	PA: 0.50 mm Ø
DX2S-5000	400 - 5000 cN	116 mm	PA: 0.80 mm Ø
DX2S-8000	1000 - 8000 cN	116 mm	PA: 1.00 mm Ø
DX2S-10K	2.5 - 10 daN	116 mm	PA: 1.00 mm Ø
DX2S-20K	5 - 20 daN	216 mm	PA: 1.50 mm Ø

Other tension ranges, measuring head widths available on request.
Other units of measure available - g or kg.
* Outer distance between outside guide rollers
Available Models

Model	Measuring Range	Resolution	Measuring Head Width*	SCHMIDT Calibration Material**
ZEF-50	0.5 - 50.0 cN	0.1 cN	43 mm	PA: 0.12 mm Ø
ZEF-100	0.5 - 100.0 cN	0.1 cN	43 mm	PA: 0.12 mm Ø
ZEF-200	1.0 - 200.0 cN	0.1 cN	43 mm	PA: 0.12 mm Ø

Other units of measure are available, such as g.
* Width of filament guide
** Suitable for 95 % of applications - PA = Polyamide Monofilament
Available Models

Model	Tension Ranges	Measuring Head Width*	SCHMIDT Calibration Material**	Material Thickness Compensator
DX2-50	10 - 50 cN	66 mm	PA: 0.12 mm Ø	no
DX2-120	20 - 120 cN	66 mm	PA: 0.12 mm Ø	no
DX2-200	20 - 200 cN	66 mm	PA: 0.12 mm Ø	no
DX2-400	20 - 400 cN	66 mm	PA: 0.20 mm Ø	no
DX2-1000	50 - 1000 cN	66 mm	PA: 0.30 mm Ø	yes
DX2-2000	200 - 2000 cN	116 mm	PA: 0.50 mm Ø	yes
DX2-5000	400 - 5000 cN	116 mm	PA: 0.80 mm Ø	yes
DX2-8000	1000 - 8000 cN	116 mm	PA: 1.00 mm Ø	yes
DX2-10K	2.5 - 10 daN	116 mm	PA: 1.00 mm Ø	yes
DX2-20K-L	5 - 20 daN	216 mm	PA: 1.50 mm Ø	yes

Other tension ranges and measuring head widths available on request.
Other units of measure available - g or kg.
* Depending on model, either width of filament guide or outer distance between outside guide rollers
** Suitable for 95 % of applications - PA = Polyamide Monofilament
Available Models

Model	Tension Range	Measuring Head Width*	SCHMIDT Calibration Material**
ZF2-5	1 - 5 cN	43 mm	thread: 25 tex
ZF2-10	1 - 10 cN	43 mm	thread: 25 tex
ZF2-12	1 - 12 cN	43 mm	thread: 25 tex
ZF2-20	2 - 20 cN	43 mm	thread: 25 tex
ZF2-30	3 - 30 cN	43 mm	PA: 0.12 mm Ø
ZF2-50	5 - 50 cN	43 mm	PA: 0.12 mm Ø
ZF2-100	10 - 100 cN	43 mm	PA: 0.12 mm Ø

Other tension ranges available on request.
Other units of measure available, such as g.
* Width of filament guide
** Suitable for 95 % of applications - PA = Polyamide Monofilament
Why Us: USD 1000 million in sales every year; Excellent quality and Competitive price; Widely professional exporting experience all over the world; Well-trained and experienced staff will answer all your inquiries professionally in any language; Good after-sales service is offered. Culture Culture:
We stick to the principle of the culture are Sustainability and Six High Standards: high-level management, high efficiency, high-qualified staff, high-level skills, high-quality products, and high-speed developing sales. The best design includes consideration for the environment. That's why we're committed to making sure our processes, products, and people follow safe and environmentally-friendly practices. Another side, We prefer to bring the newest, most fashionable, high quality, and healthiest products for our customers.

Service:
ZHENGTAIFENG METAL PRODUCT LIMITED products feature a complete presale, selling, and after-sales service system, and provide detailed management and service for clients in terms of distribution channels. and provides professional and systematic advice for distributors.
Supplementary Service:
We have an export license to assist our customers by handling export procedures. We have our team to control quality, arrange shipment, and combine containers (combine different kinds of items in one container from our factory to another). As we always care about your thinking, we will be your professional partner to source your right products in China.

Suggestion:
Please kindly check the packages after you receive the goods, if you have any problem, please get in touch with us as soon as possible.
Contact us:
More products are available in ZHENGTAIFENG. They are all at competitive prices and of good quality, just go to our company page to see the details.
If you find or do not find the products you need, please have not hesitate to let us know.
FAQ:

1. Q: Are you a factory or trading company?

A: We are a professional manufacturer. Welcome to visit us, We'll pick you up at Guangzhou Airport or Shenzhen Airport.

2. Q: Where is your factory located?

A: Our factory is located in Huizhou, Guangdong Province, next to Dongguan. Warmly welcome domestic and foreign customers to visit!

3. Q: How can I get a sample to test your quality?

A: Most samples are free except for special products. New clients are expected to pay the courier.

4. Q: How about your payment terms?

A: T/T in advance or one month after shipment

5. Q: When can you deliver the goods?

A: If stock is available, we can deliver it within 2 days. If not, that would be 5-7 working days after getting the deposit.

6. Q: Does your company accept OEM or ODM production?

A: Yes, we are experienced in operating OEM & ODM, just send the detailed requirements.
