The World′s Hot Excavator Maintenance Mobile Boring Machine

Product Description

First, product introduction
The boring machine is mainly a kind of on-site processing equipment for the on-site maintenance of construction machinery, which is mainly used for the processing and repair of small and medium-sized pipes and shaft pin holes, and is a common tool in the construction machinery maintenance industry. It is widely used in the processing and repair of pin holes, rotary holes, main arm connecting holes and hanging ring holes of various construction machinery after welding. Processing and repair of concentric holes and multi-row holes on excavators, loaders, cranes, crawler cranes and large Marine cranes, and positioning and installation can ensure the concentricity of multiple holes.

Power of main motor:	DC 220v, 1.5KW, stepless speed change (0-180 rpm)
Feed box:	stepless speed regulation, automatic feed.
Cutting motor:	220V, 120w stepless speed regulation
Specifications of boring bar:	40mm * 1500mm
Material of boring bar:	45 #
Place of Origin	shanghai china
Certification	iso
Warranty	36 month

Main motor motor power	dc 220v, 1.5kw, stepless variable (0-180 RPM).
Feed box	stepless speed regulation, automatic feed.
Cutting machine	220V, 120w stepless speed regulation
Boring range	45 mm -200 mm diameter.
Boring bar specification	40mm*1500mm (can be customized according to customer requirements)
Boring bar material	45#.
Boring bar processing process	tempering, turning, quenching, grinding, surface plating hard chromium.
Feed guide	double cylindrical guide (45# steel, quenched, tempered, ground, hard chrome plated).
Cutting feed	Min 0.10 mm/turn
Maximum cutting quantity	single side 2 mm.
Work schedule	300 mm (customer requirements can be customized).
Weight	about 60KG.
Positioning cone sleeve	aperture 40 mm, 4 pieces.
Adjustable support frame	1 set (2 before and 2 after).
Tool holder	1 set (processing aperture 90-130mm 1, 130-180mm 1).
Cutting tools	4 (W1 2 2, 2 HSS).
Hexagon socket wrench	1 set.
10 "adjustable spanner	1 set.
Top silk	M8*10mm4, M8*25mm4.
Coupling bolt	M10*65mm1.
Packing cases	2 (1 main machine, 1 boring tool bar).
Random data	1 set (operation manual and qualification certificate).

FAQ
Are you manufacture?
Yes. We are one of leading manufacturers
Do you have Stock productions to sell?
Yes, of course. But we also offer OEM service. Please send us some drawing.
What information do you want to know if i want to get a quotation?
a). The model/size of your products.
b).The application for your products.
c).Special package methods if you needs.
d). Raw material.
Do you inspect the finished products?
Yes.Each step of products will be carried out inspection by QC department until shipping
What advantages do you have?
(1) Punctual: Have your orders met with the latest delivery?
We are a manufacturer with so many advanced and new machines. It ensures we have the ability to carry out the production schedule for punctual delivery.
(2) We have over 20 years experience in this industry.
That means we can preview the problems for the orders and production. Therefore, it will make sure to deduce the risk of bad situation to happen.
(3) Point to point service.
There is two sales departments who will serve you from inquiry to products shipped out. During the process, you just need to discuss with him for all the problems and the way sames much times
Our Services
1. 24 hours on line service, support Chinese, English, Spanish, French, German, Russian ,technical guidance.
2. When meets machine failure problem, our factory will ensure that the problem is solved within 1 hour.
3. Provide machine install video.
4. Provide logistics information, like shipping by sea, shipping by express DHL, FEDEX delivery, real-time tracking service.
5. If machine is broken ,Non-human causes,the new machine will be provided or new parts will be provided.
