Marine Ship Boat Using Pneumatic Rubber Fender Meet ISO 17357-2002

Product Description

Pneumatic Rubber Fender meet ISO 17357-2002 Description
Foam fenders work equally well in harbors or between vessels. Low hull pressures protect soft-skinned ships. Foam fender combines a Durable, Non-marking finish with Low maintenance, Low reaction and high energy absorptions, No chain/tire net required, Virtually indestructible, Unsinkable design, Non-marking even against white hulls, Maintains safe stand-off distances, Low hull pressures, Wide range of standard and custom sizes, Well proven design and low maintenance and operational cost.
Characteristics
1. Using compressed air for buffering, the pneumatic rubber fender deforms gently while being squeezed and pressed. It offers a large contact surface, low reaction force and large energy absorption.
2. When a ship is berthing at an angle, the pneumatic rubber fender can achieve oblique contact with the ship due to its unique structure, thus better protecting the ship and the dock.
3. The fender is floating on water all the time, allowing a ship to safely berthing at any time without influence from the rising and fall of tidewater and sea wave, etc. Meanwhile, floating on water ensures small friction force, which ensures no damage to ship's external coating and the rubber fender itself.
4. It is very easy for installation. Bolts and nuts are not required. The one thing we need to do is to use rope to tie the marine fender to the dock or the anchor post of a ship.
Applications
typically, the pneumatic rubber fenders are tied to docks and ships to protect docks and ships from being damaged during berthing process. In addition, they can also be used as buoys, for pipe sealing and in the processing of transporting goods.

Specification(D×L)m*m	Initial inflation pressure (Po) (0.05MPa)			Initial inflation pressure (Po) (0.08MPa)
	Weight (kg)	Reaction force (kN)	Energy absorption (KJ)	Weight (kg)	Reaction force (kN)	Energy absorption (KJ)
0.5×1.0	25	64	6	25	83	8
0.6×1.0	32	74	8	32	96	11
0.7×1.5	50	137	17	50	178	24
1.0×1.5	80	182	32	80	235	44
1.0×2.0	100	257	45	125	335	63
1.2×2.0	120	297	63	165	386	86
1.35×2.5	165	427	102	226	554	140
1.5×3.0	315	597	153	370	751	211
1.7×3.0	405	639	191	436	830	263
2.0×3.5	590	875	308	632	1138	424
2.5×4.0	1050	1381	663	1110	1815	925
2.5×5.0	1333	2019	943	1410	2653	1317
3.0×5.0	1880	2104	1210	215	2709	1571
3.0×6.0	2160	2583	1485	2470	3292	1888
3.3×4.5	2020	1884	1175	2300	2476	1640
3.3×6.0	2300	2783	1675	2600	3652	2338
3.3×6.5	2700	3015	1814	3080	3961	2532
